Zebra

Zebra MC945A-3G1R6BSS-NA Handheld-Terminals

SKU:

MC945A-3G1R6BSS-NA

The MC945A-3G1R6BSS-NA pairs the SE58 Extended Range scan engine -- covering 1D and 2D barcodes from in-hand to over 100 ft./30.5 m -- with IEEE 802.11ax (Wi-Fi 6E) and 5G/4G/LTE cellular data in a gun-style chassis rated IP65 and IP68. A Snapdragon QCM4490 octa-core processor running at 2.40 GHz drives the unit, backed by 6 GB RAM and 128 GB of flash storage expandable via microSD or UFS. The 4.3-inch WVGA LED touchscreen resolves at 800 x 480 and works alongside a 34-key function numeric keypad, while Bluetooth 5.3 BLE, NFC, and USB Type-C round out connectivity. Dual nano/eSIM support enables simultaneous private and public 5G connections, and GPS with Galileo/GLONASS is included. The removable 7000 mAh Li-Ion battery at 3.60 V powers operation across -4 F (-20 C) to 122 F (50 C), with a drop rating exceeding MIL-STD-810H at 12 ft./3.65 m to concrete. A 16-megapixel rear camera and 8-megapixel front camera, Corning Gorilla Glass, and Android 13 -- upgradable to Android 17 -- complete the specification. RoHS compliant, backed by a 1-year limited warranty, and suited for warehouse, manufacturing, port, cold storage, and retail environments.
Die Preise konnten nicht aktualisiert werden.
Beschreibung
ico-plus ico-minus
Zebra MC9400

Der Zebra MC9400 bezeichnet eine Mobile-Computing-Familie. Dieser Eintrag sollte als Modell- oder Familienreferenz behandelt werden und nicht als vollstaendig konfigurationsspezifische Bestellnummer. Wenn exakte Spezifikationen wichtig sind, sollten die finale Bestellnummer, die regionale Variante, die Konnektivitaet, das Medienformat oder enthaltene Zubehoerteile vor der Veroeffentlichung anhand der offiziellen Zebra Dokumentation bestaetigt werden.

Warum diese Beschreibung sicherer ist
  • Genauigkeit auf Familienebene - vermeidet Aussagen zu Hardware, Software, Abmessungen oder Zubehoer, die fuer diese MOD Referenz nicht ausdruecklich bestaetigt sind
  • Publikationssichere Formulierung - geeignet, wenn der Datensatz eine Familie, Plattform oder ein Marketingmodell statt einer kompletten Konfiguration repraesentiert
  • Verifikation zuerst - hilft dabei, zu stark abgeleitete Spezifikationen nicht ungeprueft zu veroefentlichen

Empfohlener Hinweis fuer die Veroeffentlichung
Verwenden Sie die finale Zebra Bestellnummer fuer konfigurationsspezifische Details wie Aufloesung, Arbeitsspeicher, Konnektivitaet, Scan Engine, Medienabmessungen, Lizenzstufe oder Packungsmenge.

Hauptmerkmale

  • System: Android

  • Robust: Industrial

  • Bereich: Extended Range

  • Verbindung: USB, Bluetooth

Technische Spezifikationen
ico-plus ico-minus
Technical Information
Connectivity Technology Wireless
Scanning Capability
  • 1D
  • 2D
Scan Engine Model SE58
Image Sensor Type Imager
Light Source Laser
Scanner Range Extended Range
Google Mobile Services (GMS) Yes
Sensor Type
  • Accelerometer
  • Motion Sensor
  • Gyroscope
  • eCompass
  • Light Sensor
  • Magnetometer
Multi-SIM Supported Yes
SIM Size Supported Nano/eSIM
Features
  • Corning Gorilla Glass
  • Push-to-talk
  • Non Incendive
  • Drop Resistant
  • VoIP
Drop Specification
  • Exceeds per MIL-STD-810H: 12 ft./3.65 m to concrete;
  • Enterprise drop standard 8 ft. (2.4 m) to concrete across temperature (-20°C to 50°C) exceeding MIL-STD-810H
Processor & Chipset
Processor Type Snapdragon
Processor Model QCM4490
Processor Core Octa-core (8 Core)
Processor Speed 2.40 GHz
Memory
Standard Memory 6 GB
Flash Memory 128 GB
Memory Card Supported
  • microSD
  • UFS
Display & Graphics
Screen Size 4.3"
Screen Mode WVGA
Screen Resolution 800 x 480
Display Screen Type LED
Touchscreen Information
Touchscreen Yes
Keyboard/Keypad
Number of Keys 34
Keyboard Type Function Numeric
Network & Communication
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ax
Bluetooth Yes
Bluetooth Standard Bluetooth 5.3 BLE
Near Field Communication (NFC) Yes
Cellular Data Connectivity Technology
  • 5G
  • 4G
  • 3G
  • 2G
  • LTE
GPS Yes
Global Navigation Satellite System (GNSS) Supported Galileo/GLONASS
Interfaces/Ports
USB Yes
USB Type-C Yes
Camera
Front Camera Yes
Front Camera Resolution 8 Megapixel
Rear Camera Yes
Rear Camera Resolution 16 Megapixel
Software
Operating System Android 13
Upgradable Operating System Android 17
Power Description
Power Source Battery
Battery Information
Battery Capacity 7000 mAh
Battery Chemistry Lithium Ion (Li-Ion)
Battery Included Yes
Battery Voltage 3.60 V
Removable Battery Yes
Environmental Conditions
Operating Temperature -4°F (-20°C) to 122°F (50°C)
Storage Temperature -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing) 5% to 95%
Physical Characteristics
Form Factor Gun
Rugged Yes
Height 7.4"
Width 3.5"
Length 9.4"
Weight (With Battery) 1.64 lb
Miscellaneous
Package Contents
  • MC9450 Handheld Terminal
  • Battery
Application/Usage
  • Warehouse
  • Distribution
  • Cold Storage
  • Inventory Management
  • Manufacturing
  • Safety Testing
  • Retail
  • Backroom Inventory Management
  • Store Receiving
  • Port
  • Yard
Ingress Protection (IP) Rating
  • IP65
  • IP68
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty 1 Year
