Zebra

Zebra DS4801-DL00004ZZNA Barcodescanner

SKU:

DS4801-DL00004ZZNA

Das Zebra DS4801-DL00004ZZNA ist ein barcode scanner der DS4800-Serie. Bietet hohe Erstleseraten für Standard- und beschädigte Barcodes in Einzelhandels-, Lager- und Gesundheitsumgebungen.
Beschreibung
ico-plus ico-minus

The Motorola DS4800 Barcode Scanner combines cutting-edge technology with elegant design, ensuring that you not only maintain efficiency at your point of sale but also enhance the overall customer experience. Its sophisticated ergonomics allow for comfortable use while the scanner seamlessly captures both 1-D and 2-D barcodes, whether printed or displayed on mobile devices. Customizable to match your brand, the DS4800 offers a unique scanning experience with its modern capacitive touch trigger and intuitive feedback options, keeping your checkout lines flowing smoothly.


Key features:
  • High-performance scanning: Effectively captures 1-D and 2-D barcodes, including those on mobile screens.
  • Customizable design: Available in multiple colors and styles to align with your brand.
  • Innovative touch trigger: Allows cashiers to choose their preferred scanning method.
  • Flexible operation: Switch effortlessly between handheld and hands-free modes.
  • Impressive durability: Withstands drops and has an IP40 rating for reliability in retail environments.

Specifications:
  • Dimensions: 7.47 in. L x 2.61 in. W x 1.90 in. H
  • Weight: 6 oz. (168 g)
  • Power Source: USB VBUS, 5VDC
  • Supported Host Interfaces: USB
  • Scanning Performance: Up to 20 in./sec; Skew Tolerance: 86°; Pitch Tolerance: 82°
  • Operating Temperature: 32° F to 104° F (0° C to 40° C)
  • Drop Specification: Withstands multiple 5 ft. drops to concrete
  • Warranty: 5 years for the scanner, 30 days for the cable

Hauptmerkmale

  • Konnektivität: Corded

  • Verbindung: USB

  • Scanner-Funktionalität: 2D, Imager

Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Cable
Scanning Capability
  • 1D
  • 2D
Barcode Symbology Supported 1D:
  • UPC/EAN
  • UPC/EAN with supplementals
  • Bookland EAN
  • ISSN
  • UCC Coupon Extended Code
  • Code 128
  • GS1- 128
  • ISBT 128
  • Code 39
  • Code 39 Full ASCII
  • Trioptic Code 39
  • Code 32
  • Code 93
  • Code 11
  • Matrix 2 of 5
  • Interleaved 2 of 5
  • Discrete 2 of 5
  • Codabar
  • MSI
  • Chinese 2 of 5
  • GS1 DataBar variants
  • Korean 3 of 5
  • ISBT Concatenated
2D:
  • PDF417
  • MicroPDF417
  • Composite Codes
  • TLC-39
  • Data Matrix
  • Maxicode
  • QR Code
  • MicroQR
  • Aztec
  • Han Xin
Postal:
  • Australian Post
  • US PLANET
  • Royal Mail 4 State Customer
  • US POSTNET
  • KIX Code (Dutch)
  • UK Postal
  • Japan Post
  • UPU 4 State Postal FICS (Post US4)
  • USPS 4 State Postal (Post US3)
Image Sensor Type Imager
Interfaces/Ports
Host Interface USB
Physical Characteristics
Color Midnight Black
Height 1.9"
Width 2.6"
Length 7.5"
Weight (Approximate) 6 oz
Miscellaneous
Additional Information

USB Cable separate

Environmentally Friendly Yes
Environmental Certification RoHS
Warranty
Limited Warranty 5 Year
