Datamax I16-00-46000007 Etikettendrucker
I16-00-46000007
Modell auswählen
The Datamax-O'Neil I-4212e Barcode Label Printer is a versatile, mid-range industrial printer designed to streamline your barcode printing needs. With its rugged construction and advanced features like the ECO IntelliSEAQ™ print head, this printer offers superior durability and consistent quality. Its multiple connectivity options ensure seamless integration into existing systems, making it the perfect choice for applications in manufacturing, logistics, and pharmaceuticals. Enjoy efficient label production with significantly reduced power consumption, making it an eco-friendly solution without compromising performance.
Key Features
- OPTIMedia Technology: Automatically adjusts heat and speed for optimal print quality.
- Lower Power Consumption: Consumes 25% less power than competitors.
- Multiple Communication Ports: Includes serial, parallel, USB, LAN, and more.
- 7-button LCD Display: User-friendly interface for easy label setup.
- Rugged Construction: Durable die-cast aluminum frame for enhanced longevity.
- Quick Maintenance: Change printhead and platen roller in under five minutes.
- Multi-Language Menu: Available in English, Spanish, German, Italian, and French.
Specifications
- Max Print Width: 4.10" (104.1 mm)
- Max Print Length: 0.25" - 99" (6.35 - 2514.6 mm)
- Print Speed: 12 IPS (304 mm/s)
- Resolution: 203 DPI (8 dots/mm)
- Memory: 32MB SDRAM / 64MB Flash
- Dimensions: 12.7" H x 12.62" W x 18.6" D (322.6mm x 320.5mm x 472.4mm)
- Weight: 45 lbs. (20.5 kg)
- Operating Temperature: 32°F to 104°F (0°C to 40°C)
- Power Source: Auto-sensing 90-132 or 180-264 VAC @ 47-63Hz
Hauptmerkmale
-
Ausrüstungsformat: Desktop
-
Robust: Industrial
-
Gehäusefarbe: Black
-
Verbindung: Serial, USB
| Technical Information | |
|---|---|
| Recommended Use | Label Print |
| Print Color Capability | Monochrome |
| Maximum Mono Print Speed | 5.99 in/s |
| Maximum Print Resolution (dpi) | 600 |
| Maximum Print Width | 4.17" |
| Barcode Symbology Supported |
|
| Real Time Clock | Yes |
| Application/Usage | Desktop |
| Features |
|
| Print Technology | Direct Thermal /Thermal Transfer |
| Memory | |
|---|---|
| Standard Memory | 32 MB |
| Memory Technology | SDRAM |
| Flash Memory | 64 MB |
| Interfaces/Ports | |
|---|---|
| Parallel Port | Yes |
| Serial Port | Yes |
| USB | Yes |
| Display & Graphics | |
|---|---|
| Display Screen | Yes |
| Display Screen Type | LCD |
| Media Types & Handling | |
|---|---|
| Media Type |
|
| Media Sensor |
|
| Media Thickness | 10 mil |
| Maximum Roll Diameter | 8" |
| Maximum Label Width | 4.65" |
| Label Core Size | 3" |
| Fonts & Emulation | |
|---|---|
| Language Emulation |
|
| Power Description | |
|---|---|
| Power Source | AC Supply |
| Physical Characteristics | |
|---|---|
| Color Family | Black |
| Product Color | Black |
| Height | 12.7" |
| Width | 12.6" |
| Depth | 18.6" |
| Weight (Approximate) | 45.20 lb |
| Miscellaneous | |
|---|---|
| Platform Supported | PC |
