Zebra

Zebra TerraScout 6 Pro Mobile Computer, Wi-Fi 6E, 6.0" Display, 8GB RAM, 64GB Storage, IP65

SKU:

TC5301-0T1E7B1000-NA

Zebra TC53 Mobile Computer — Zebra TerraScout 6 Pro: A versatile rugged Android handheld built for demanding mobile operations, providing robust scanning, secure connectivity, and enterprise management capabilities to support logistics, inventory, and field workforce tasks. Attributes: SSD, RFID, GPS, Healthcare, Pin.
Description
ico-plus ico-minus
The **Zebra TC53 Mobile Computer** is a revolutionary device that transforms the way you collect and manage data in any work environment. With its next-generation Qualcomm 6490 octa-core processor, a stunning 6-inch high-definition display, and robust wireless capabilities, including **5G** and **Wi-Fi 6E**, this mobile computer is designed to enhance productivity and streamline operations. Its durable design, coupled with a lightweight build, makes the TC53 perfect for demanding tasks, whether it’s for retail, field service, or logistics. Experience unparalleled performance with cutting-edge scanning technology and powerful battery life to keep your workforce connected and efficient.
Key features:
  • **Powerful Qualcomm 6490 octa-core processor** with up to 8 GB RAM for blazing speed
  • **Advanced 6-inch display** with edge-to-edge technology for easy readability indoors and outdoors
  • **Unmatched battery technology** with standard 4400 mAh and extended 6600 mAh options
  • **Integrated 16 MP camera** for ultra-high resolution photos and video intelligence
  • **Variety of scanning options** to meet all your data collection needs
  • **Comprehensive accessory compatibility** for various operational needs
  • **Mobility DNA tools** for enhanced security and productivity management

Specifications:
  • Dimensions: 6.48 in. L x 3.04 in. W x 0.66 in. H
  • Weight: 10.3 oz. / 293 g with standard battery
  • Display: 6.0 in. Full HD (1080 x 2160), LED backlight, 600 NITS
  • Processor: Qualcomm 6490 octa-core, 2.7 GHz
  • Operating System: Android 11 (upgradeable to Android 14)
  • Memory Options: Up to 8GB RAM and 128GB Flash
  • Battery: PowerPrecision+ technology; supports Qi wireless charging
  • Camera: Rear 16 MP with Optical Image Stabilization (OIS)
  • Connectivity: Wi-Fi 6E, Bluetooth v5.2, 5G for advanced data and voice communication
  • Drop Specifications: Multiple 6 ft drops to concrete
  • IP Ratings: IP68 and IP65 for dust and water resistance

Main Features

  • Operation System: Android

  • Rugged: Commercial

  • Equipment Format: Phone

  • RAM/FLASH: 8GB / 64 GB

  • Battery Capacity: Standard

  • IP Rating: IP65

  • Range: Short Range

  • Connection: 5G, NFC

  • Pin: 8

  • Camera: 16MP Rear Facing Camera + 8MP Front Facing Camera

  • Battery Features: Warm Swap

Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Wireless
Scanning Capability
  • 1D
  • 2D
Scan Engine Model SE4720
Image Sensor Type Imager
Scanner Range Standard Range
Google Mobile Services (GMS) Yes
Sensor Type
  • Light Sensor
  • Magnetometer
  • Motion Sensor
  • Pressure Sensor
  • Proximity
  • Gyroscope
  • Accelerometer
  • eCompass
Brightness 600 Nit
Features
  • Corning Gorilla Glass
  • Push-to-talk
Drop Specification
  • Multiple 6 ft./1.8 m drops to concrete over operating temp (-20°C to 50°C/-4°F to 122°F) with protective boot per MIL STD 810H
  • Multiple 5 ft./1.5 m drops to tile over concrete (-10°C to 50°C/14°F to 122°F) per MIL STD 810H
Processor & Chipset
Processor Model 6490
Processor Core Octa-core (8 Core)
Processor Speed 2.70 GHz
Memory
Standard Memory 8 GB
Flash Memory 64 GB
Display & Graphics
Screen Size 6"
Screen Resolution 1080 x 2160
Display Screen Type LED
Touchscreen Information
Touchscreen Yes
Network & Communication
Wireless LAN Yes
Bluetooth Yes
Bluetooth Standard Bluetooth 5.2
Interfaces/Ports
USB Yes
USB Type-C Yes
Camera
Front Camera Yes
Front Camera Resolution 8 Megapixel
Rear Camera Yes
Rear Camera Resolution 16 Megapixel
Software
Operating System Android
Power Description
Power Source Battery
Battery Information
Battery Capacity 4680 mAh
Battery Chemistry Lithium Ion (Li-Ion)
Battery Included Yes
Environmental Conditions
Operating Temperature -4°F (-20°C) to 122°F (50°C)
Storage Temperature -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing) 5% to 95%
Physical Characteristics
Form Factor Phone-size
Rugged Yes
Height 0.7"
Width 3"
Length 6.5"
Weight (With Battery) 10.34 oz
Miscellaneous
Package Contents
  • TC53 Handheld Terminal
  • Battery
    		•
    Application/Usage
    • Retail
    • Field Sales/Service
    Ingress Protection (IP) Rating
    • IP65
    • IP68
    TAA Compliant Yes
    Environmentally Friendly Yes
    Environmental Compliance Restriction of Hazardous Substances (RoHS)
    Warranty
    Limited Warranty 1 Year
    Documents
    ico-plus ico-minus
    Product document tc53-tc58.pdf TC5301-0T1E7B1000-NA Product document tc53-tc58.pdf MOD-TC53
