Zebra

Zebra MC3400 Mobile Computer Pistol Grip, 38-Key, SE4770, 6GB/64GB, Wi-Fi 6E, Android 13 GMS

SKU:

MC3401-0G1J53SS-NA

Mobile Handheld Computer, Zebra MC3400, LAN, Wi-Fi 6E, Gun, Bluetooth, NFC, 4.0" Display, Vibrator, Android GMS, SE4770 Imager, 6GB RAM / 64GB UFS, 38 Key, 7000mAh Standard Battery, North America Only (US, CA, PR)
Description
ico-plus ico-minus

The Zebra MC3400 Mobile Computer is engineered for the most demanding environments, delivering advanced connectivity with Wi-Fi 6E and 5G capabilities. This next-generation device offers 2.5x the processing power of its predecessors, ensuring that your workforce can handle today's fast-paced e-commerce economy with ease. With options like biometric facial recognition for security and versatile scanning capabilities, the MC3400 empowers your team to work productively and efficiently across various applications. Rugged and durable, it's built to withstand the rigors of everyday use while providing superb reliability.


Key Features:
  • Advanced Connectivity: Supports Wi-Fi 6E and 5G for fast wireless communication.
  • Powerful Performance: Qualcomm® 4490 processor provides 2.5 times more power.
  • Enhanced Scanning Options: Multiple scan engines available for various needs.
  • Rugged Design: Drop, tumble, dust, and waterproof for maximum durability.
  • Biometric Security: Instant access through facial recognition technology.

Specifications:
  • Dimensions: Straight Shooter: 8.2 in L x 2.9 in W x 1.5 in H; Gun: 8.2 in L x 2.9 in W x 6.5 in H
  • Weight: Straight Shooter: 15.6 oz; Gun: 18.6 oz
  • Display: 4 in WVGA (800 x 480), 350 NITS (typical), up to 600 NITS (expanded)
  • Camera: Front: 5 MP; Rear: 13 MP with autofocus
  • Battery: 3.6V, 7000mAh Lithium-Ion; hot-swap capability
  • Networking: WLAN, WPAN (Bluetooth), USB 2.0; optional 5G connectivity on MC3450
  • Operating System: Android upgradeable to future versions
  • Drop Specification: Tested to withstand falls from 8 ft
  • Environmental Ratings: IP65 and IP67 for dust and water resistance

Main Features

  • Operation System: Android

  • Rugged: Industrial

  • Range: Standard Range

  • Connection: USB, Bluetooth

  • Keyboard: 38 Key Function Numeric

  • Camera: None

Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Wired/Wireless
Scanning Capability
  • 1D
  • 2D
Scan Engine Model SE4770
Image Sensor Type Imager
Light Source Laser
Scanner Range Extended Range
Scanning Distance 100 ft
Google Mobile Services (GMS) Yes
Sensor Type
  • Light Sensor
  • Magnetometer
  • Motion Sensor
  • Accelerometer
  • Gyroscope
Brightness 600 Nit
Features
  • Gorilla Glass
  • Corning Gorilla Glass
  • Multi-color LED Notification
  • Push-to-talk
  • VoIP
Drop Specification

Per MIL-STD 810H: 8 ft (2.4m)7 to concrete at (+23C/+73F); 6 ft (1.8m) to concrete across temperature (-20C to +50C/-4F to +122F) exceeding MIL-STD-810H
Processor & Chipset
Processor Model QCM4490
Processor Core Octa-core (8 Core)
Processor Speed 2.40 GHz
Memory
Standard Memory 6 GB
Flash Memory 64 GB
Memory Card Supported microSD
Display & Graphics
Screen Size 4"
Screen Mode WVGA
Screen Resolution 800 x 480
Touchscreen Information
Touchscreen Yes
Keyboard/Keypad
Number of Keys 38
Keyboard Type Function Numeric
Network & Communication
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc
Bluetooth Yes
Bluetooth Standard Bluetooth 5.3 BLE
Near Field Communication (NFC) Yes
Interfaces/Ports
USB Yes
USB Type-C Yes
Camera
Front Camera Yes
Front Camera Resolution 5 Megapixel
Software
Upgradable Operating System Android 15
Power Description
Power Source Battery
Battery Information
Battery Capacity 7000 mAh
Battery Chemistry Lithium Ion (Li-Ion)
Battery Included Yes
Battery Voltage 3.60 V
Removable Battery Yes
Environmental Conditions
Operating Temperature -4°F (-20°C) to 122°F (50°C)
Storage Temperature -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing) 5% to 95%
Physical Characteristics
Form Factor Gun
Rugged Yes
Height 6.5"
Width 2.9"
Length 8.2"
Weight (Approximate) 1.16 lb
Miscellaneous
Package Contents
  • MC3400 Mobile Computer
  • Battery
Application/Usage
  • Retail
  • Backroom Inventory Management
  • Order Picking
  • Store Receiving
  • Logistics
  • Yard
  • Asset Tracking
  • Inventory Management
Ingress Protection (IP) Rating
  • IP65
  • IP67
TAA Compliant Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty 1 Year
Documents
ico-plus ico-minus
Product document mc3400-mc3450.pdf MC3401-0G1J53SS-NA Product document mc3400-mc3450.pdf MOD-MC3400
