Honeywell

Honeywell HF810 Barcode Scanner Wide Angle, 2D, Area Imager, DPM, IP65, Black

SKU:

HF810-11WT00004K-R

Honeywell Pro 2D Imager delivers fixed-mount industrial scanning with a wide-angle 0.5 MP area imager and dedicated DPM support for demanding production environments. Built for flexible integration, it connects through RS232, RS485, or Ethernet and is protected to IP65 for reliable use in industrial applications.
Description
ico-plus ico-minus

The Honeywell 2DGuard is a fixed‑mount industrial barcode scanner engineered for reliable hands‑free capture of 1D, 2D and Direct Part Marking (DPM) codes in manufacturing, warehouse and automated production environments. Built on the HF81X family and centered on a 0.5 MP area imager with configurable illumination options, the 2DGuard delivers consistent decoding of QR, DataMatrix, Aztec, Maxicode and PDF417 across a wide depth of field. Its compact, IP65‑rated housing and multiple industrial interfaces (Ethernet, RS232, RS485) enable straightforward integration into PLCs, conveyors and vision stations, improving throughput, traceability and uptime for B2B deployments that require rugged, repeatable scan performance.

Key Features

  • Fixed‑mount form factor: Designed for stable, hands‑free scanning points to support automation, inspection and conveyor‑based workflows.
  • DPM capable: Supports direct part marking decoding for traceability and component identification without labels.
  • Broad symbology support: Reliable decoding of 1D and 2D codes including QR, DataMatrix, Maxicode, Aztec and PDF417 to cover diverse application needs.
  • Industrial connectivity: Ethernet, RS232 and RS485 interfaces provide flexible integration with existing control and host systems.
  • Rugged, compact design: IP65 protection and a small enclosure allow deployment in harsh environments while minimizing footprint at the scan station.

Specifications

  • Brand: Honeywell
  • Product Name: Honeywell 2DGuard
  • Model / Series: HF810 / HF81X
  • Product Type: Barcode Scanner
  • Form Factor: Fixed Mount
  • Color: Black
  • Image Sensor Type: Imager (area)
  • Image Sensor Resolution: 0.5 MP
  • Illumination Color: Red / White / Blue (variant dependent)
  • Scanning Capability: 1D, 2D, DPM, PDF417
  • Direct Part Marking (DPM) Decoding: Yes
  • Host Interfaces: Ethernet, RS232, RS485
  • Connectivity Technology: Cable
  • Ingress Protection (IP) Rating: IP65
  • Depth of Field: 0-1000 mm
  • Field of View (Horizontal): 20°
  • Field of View (Vertical): 11°
  • Maximum Ambient Light: 100000 lux
  • Width: 2.17 in (55 mm)
  • Depth: 1.77 in (45 mm)
  • Height: 2.76 in (70 mm)
  • Input Voltage: 240 V
  • Output Voltage: 24 V
  • Power Supply Type: AC (requires separate power supply unit)
  • Manufacturer Part Number (example variant): HF810-01RT00004K-R

Main Features

  • Rugged: Industrial

  • IP Rating: IP65

  • Connection: Serial, Ethernet

  • Scanner Capability: 2D, Imager

Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Cable
Scanning Capability
  • 1D
  • 2D
Barcode Symbology Supported
  • 1D
  • DPM
  • PDF 417
  • 2D (QR, Datamatrix, Maxicode, Aztec)
Image Sensor Type Imager
Cable Type Included USB
Field of View (Horizontal) 39°
Field of View (Vertical) 22°
Maximum Ambient Light 100000 lux
Direct Part Marking (DPM) Decoding Yes
Interfaces/Ports
Host Interface
  • Serial
  • Ethernet
Physical Characteristics
Form Factor Fixed Mount
Color Family Black
Product Color Black
Height 2.8"
Width 2.2"
Depth 1.8"
Weight (Approximate) 6.35 oz
Miscellaneous
Package Contents
  • HF810 Fixed Mount Scanner
  • USB
Ingress Protection (IP) Rating IP65
Application/Usage
  • Industrial
  • Manufacturing
  • Warehouse
Warranty
Limited Warranty 3 Year
Documents
ico-plus ico-minus
Product document hf81x-2022.pdf HF810-11WT00004K-R Product document mod-hf810-honeywell-presentation-readers-datasheet.pdf MOD-HF810 Product document mod-hf810-honeywell-presentation-readers-quick-guide.pdf MOD-HF810 Product document mod-hf810-honeywell-presentation-readers-user-manual.pdf MOD-HF810
FAQs
ico-plus ico-minus
What barcode types can the Honeywell HF810 decode, and does it support Direct Part Marking?
The Honeywell HF810 decodes 1D and 2D symbologies including QR, DataMatrix, Maxicode, Aztec, and PDF417, and it fully supports Direct Part Marking (DPM) decoding for component traceability without labels.
What industrial interfaces does the Honeywell HF810 offer for integration with PLCs and host systems?
The HF810 provides Ethernet, RS232, and RS485 interfaces, enabling wired integration with PLCs, conveyors, vision stations, and other control systems.
What is the depth of field and field of view of the Honeywell HF810 fixed mount scanner?
The HF810 has a depth of field of 0 to 1000 mm, a horizontal field of view of 20°, and a vertical field of view of 11°.
Is the Honeywell HF810 rated for use in harsh or dusty manufacturing environments?
Yes, the HF810 carries an IP65 ingress protection rating and is designed for rugged industrial deployment, with a maximum ambient light tolerance of 100,000 lux.
What are the physical dimensions of the Honeywell HF810, and what power supply does it require?
The HF810 measures 55 mm wide, 45 mm deep, and 70 mm tall, and it operates on a 24 V DC output drawn from a separately sourced AC power supply unit accepting 240 V input.
