Zebra

TTP 2110 SER DESKTP

SKU:

01991-100

Configured with an RS-232 serial interface for desktop deployment, the Zebra 01991-100 is a direct thermal ticket printer that prints monochrome output at 203 dpi and up to 5.91 in/s across a maximum print width of 3.25 inches. Variable ticket formats run up to 3.25 inches wide and 23.6 inches long, covering ATB1 boarding passes and IATA CUSS bag tags up to 21 inches in length, while an automatic media detector enables loading without manual adjustment. The printer accepts fanfold and continuous label stock up to 9.84 mil thick on rolls to 9.84 inches in diameter. Both serial and USB interfaces are supported. At 2.6 inches tall, 4.1 inches wide and 7.1 inches deep, the chassis suits attended desktop ticketing environments and PC-based platforms.
Prices could not be updated.
Description
ico-plus ico-minus
The Zebra TTP 2130 is a direct thermal kiosk ticket printer designed for system integrators, kiosk OEMs, and IT procurement teams deploying self-service or attended ticketing solutions. Built around the TTP 2100 series platform, it handles ATB1 boarding passes, IATA CUSS bag tags, and general ticketing formats at a print speed of 6"/152 mm per second with 203 dpi resolution, keeping queues moving in high-throughput environments such as airports, transit hubs, entertainment venues, and hospitality kiosks. Its USB interface enables plug-and-play integration with Windows drivers, while its compact embedded footprint — 4.1" wide, 2.6" high, and 5.7" deep — fits neatly into custom kiosk enclosures. An automatic media detector loads roll or fanfold stock without manual adjustment, reducing operator intervention and minimizing downtime across unattended deployments.

Main Features

  • Connection: Serial, USB

  • Printing Technology: Direct Thermal

Technical Specifications
ico-plus ico-minus
Technical Information
Recommended Use Ticket Print
Print Color Capability Monochrome
Maximum Mono Print Speed 5.91 in/s
Maximum Print Resolution (dpi) 203
Maximum Print Width 3.25"
Application/Usage Desktop
Interfaces/Ports
Serial Port Yes
USB Yes
Media Types & Handling
Media Type
  • Fanfold
  • Continuous Label
Media Thickness 9.84 mil
Maximum Roll Diameter 9.84"
Physical Characteristics
Height 2.6"
Width 4.1"
Depth 7.1"
Miscellaneous
Platform Supported PC
Documents
ico-plus ico-minus
Product document mod-ttp-2130-zebra-receipt-printers-datasheet.pdf 01991-100  (PDF) Product document mod-ttp-2130-zebra-receipt-printers-user-manual.pdf 01991-100  (PDF) Product document ttp2100-zebra.pdf 01991-100  (PDF)
