Tripp-Lite

Tripp-Lite OMNI900LCD Accessories

SKU:

OMNI900LCD

Tripp Lite UPS 900VA 475W Battery Back Up Tower LCD AVR 120V USB - 900VA/475W - 3 Minute Full Load - 4 x NEMA 5-15R - Battery/Surge-protected, 4 x NEMA 5-15R - Surge-protected
ico-puzzle-piece-02 This product is compatible with...
Description
ico-plus ico-minus
Products and parts from Tripp-Lite.
Technical Specifications
ico-plus ico-minus
Technical Information
Plug/Connector Type NEMA 5-15P
Receptacle Type NEMA 5-15R
Receptacle Detail 8 x NEMA 5-15R
Transfer Time 3 ms
Power Description
Load Capacity (VA) 900 VA
Load Capacity (Watt) 475 W
Input Voltage 110 V AC
Input Current 12 A
Output Voltage 120 V AC
Waveform Type Pulse-width Modulated Sine Wave
Surge Energy Rating 870 J
Management
Alarm AC Input Failure
Controls/Indicators
Status Indicators

Front panel LCD screen with blue backlight offers:

  • Continuous input line voltage data
  • UPS status information on line power status
  • Battery power status
  • Battery charge level
  • Voltage regulation operation
Interfaces/Ports
USB Yes
Battery Information
Backup/Run Time (Full Load) 3 Minute
Backup/Run Time (Half Load) 10 Minute
Battery Life 6 Year
Typical Battery Recharge Time 20 Hour
Hot Swappable Yes
Environmental Conditions
Maximum Operating Temperature 122°F (50°C)
Physical Characteristics
Color Family Black
Product Color Black
Height 11.8"
Width 3.7"
Depth 7.2"
Form Factor Tower
Weight (Approximate) 14.90 lb
Miscellaneous
Package Contents
  • OmniSmart OMNI900LCD 900 VA Tower UPS
  • Manual with Warranty Information
Additional Information
  • Low voltage transfer to battery power: Switches to battery power as line voltage decreases to 89V or less, switches back to AC mode as line voltage increases to 94V or higher
  • High voltage transfer to battery power: Switches to battery mode as line voltage increases to 139V or higher, switches back to AC mode as line voltage decreases to 135V or lower
  • Network monitoring port: Single built-in USB port supports on battery, low battery and power restored messaging. Interface supports timed inverter shutoff after unattended shutdown. Compatible with Tripp Lite's PowerAlert and Watchdog service software
  • Compatible with Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application / OS or hard power off/on reboot of connected equipment ideal for unattended kiosk applications
  • Switches: Includes 2 front panel switches - one main on/off power switch and one dual function "alarm cancel" / "self test" button
  • Entry-level PCs, networked workstations, point-of-sale equipment, small business phone systems, audio/video equipment and home theater systems. Ideal for sensitive electronic applications in areas where brownout conditions are common
Certifications & Standards
  • UL1778 (TUV)
  • cUL (TUV)
  • NOM
  • FCC Class B
Software Included PowerAlert software
Country of Origin Taiwan
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty 3 Year
