Microscan 8213-2250-0104 Fixed Mount Scanners

The Microscan MV-4000 Barcode Scanner is designed for precision and versatility in machine vision applications. Compact yet powerful, this scanner boasts advanced CMOS technology and a variety of model options to suit different needs. With multiple resolutions and frame rates, it can handle an extensive range of tasks, from reading barcodes to ensuring quality control. The robust design provides extended operational capabilities while maintaining a temperature range of 0°C to 50°C. Ideal for various industries including manufacturing, logistics, and healthcare, the MV-4000 ensures reliability and efficiency in every scan.

• **High-resolution options** ranging from 640x480 to 2592x2048 pixels.
• **Multiple model configurations** including color and monochrome sensors.
• **Fast frame rates** up to 240 FPS for real-time scanning.
• **Robust design** with IP67 rating for dust and moisture resistance.
• **Flexible connectivity** with Gigabit Ethernet, VGA, and USB interfaces.

• Dimensions: 75 mm x 75 mm x 54 mm (2.95” x 2.95” x 2.13”)
• Weight: 460.39 g (16.24 oz.)
• Processor: Dual Core
• Memory: 2GB RAM
• Storage: 32GB
• Operating Temperature: 0° C to 50° C (32° F to 122° F)
• Power Consumption: 450 mA @ 24VDC or 10.8W (typical)
• Shutter Speed: 50 μsec to 4 sec
• IP Rating: IP67 (with lens cap)
• Digital I/O: 3 optocoupled inputs, 1 dedicated optocoupled trigger
