InfinID
InfinID MODEL-8159 Tags
SKU:
MODEL-8159
The V-Tag Model INF-VT100-A6 is a compact active RFID tag that generates its own mesh network. V-Tag Location Tracking System is accomplished by setting up a fixed tag attached to wall, ceiling, fences and posts around the location being monitored. Track and monitor your assets without costly infrastructure. The moveable tags then calculate their own positions based on the signals received from the fixed tags and from other neighboring tags.
Select model
Description
The InfinID V-Tag INF-VT100-A6 is a state-of-the-art active RFID tag designed for optimal asset tracking and monitoring. Compact and lightweight, this robust tag boasts its own mesh network capability, allowing seamless interaction with fixed tags. Its multipurpose functionality includes temperature monitoring, battery level reporting, and an accelerometer for immediate alerts during threshold events. With an impressive 6-year battery life and a range of tracking capabilities, the V-Tag is an essential tool for businesses aimed at enhancing operational efficiency without the burden of costly infrastructure.
Key Features
- Location Tracking System (LTS): Receive real-time location updates via fixed and movable tags.
- Temperature Monitoring: Operable in a range of -50°C to +75°C.
- Battery Level Alerts: Keep track of battery usage with accuracy of ±0.003V.
- Accelerometer: Detect immediate alerts based on movement.
- Long Battery Life: 6-year battery ensures longevity.
Specifications
- Model: INF-VT100-A6
- Dimensions: 2.75in x 2.25in x 0.75in
- Weight: 1.9 Oz
- Frequency Band: 2.4 GHz
- Battery: 3.0V 6000-mAh (Replaceable)
- Ingress Protection Rating: IP 63
- Latency Reporting: Customizable reporting intervals (15 mins to 24 hrs)
- Data Storage: 1 Megabyte Firmware
- Max Range: Up to 300ft per hop with 20 hops per gateway
- Network Size: Up to 48,000 tags per gateway
Documents
inf-vt100-a6.pdf MODEL-8159
