RK40 IClass Reader (ICLASS, SE E, LF OFF, HF SIO/SEOS, WIEG, TERM, Black)

The HID iCLASS RK40 6130 Access Control Reader is a cutting-edge security solution designed to enhance your access control systems. Featuring 13.56 MHz contactless technology, this reader supports dual-factor authentication for added security through the combination of a secure PIN and iCLASS® card. With a sleek design and weatherproof keypad, it ensures reliable performance in various environments. The RK40 easily integrates with existing systems, offering flexible configuration options while providing a user-friendly experience via backlit numbers and audio/visual indications for access events.

Key features:

• Dual-Factor Authentication: Secure PINs combined with iCLASS® card access.
• Flexible Configuration: Various PIN pad outputs compatible with multiple panels.
• Backlit Keypad: Illuminated numbers for use in low-light conditions.
• Robust Design: Weatherproof, vandal-resistant features for durability.
• Easy Integration: Compatible with existing Wiegand and Clock-and-Data systems.

Specifications:

• Power Supply: 5-16 VDC
• Current Requirements: 85mA AVG, 116mA PEAK
• Operating Temperature: -31° to 150° F (-35° to 65° C)
• Operating Humidity: 5% to 95% relative humidity non-condensing
• Transmit Frequency: 13.56 MHz
• Card Compatibility: iCLASS® credentials, MIFARE® & DESFire
• Dimensions: 3.3" x 4.8" x 1.1" (8.5 cm x 12.2 cm x 2.8 cm)
• Housing Material: UL94 Polycarbonate
• Warranty: Lifetime against defects in materials and workmanship
