Elo 1002L, 25.4 cm (10''), Projected Capacitive, 10 TP, black
E155834
Select model
Key Features
- 13-inch LCD touchscreen with Edge-to-edge design
- Integrated 10-touch support for enhanced interactivity
- Commercial-grade durability and efficiency
- USB Type-C for power, touch, and video connectivity
- Multiple mounting options including stand, wall, and pole mounts
- Compatible with finger, glove, and stylus inputs
Specifications
- Color: Black
- Diagonal Size: 13.3" / 337.82 mm
- Active Touch Area: 11.57" x 6.5" / 293.76 mm x 165.24 mm
- LCD Technology: Active matrix TFT LCD
- Touch Technology: TouchPro PCAP
- Aspect Ratio: 16:9
- Native Resolution: 1920 x 1080
- Brightness: 300 nits (Panel), 270 nits (with TouchPro PCAP)
- Input Power: 12VDC +/-5%
- Weight: 5.11 lbs. / 2.32 kg (with stand)
- Operating Temperature: 0° C to 40° C
- Warranty: 3 years
Main Features
-
Touch: Yes
-
Connection: USB
| Technical Information | |
|---|---|
| Screen Size Class | 10" |
| Viewable Screen Size | 10.1" |
| Screen Mode | WXGA |
| Screen Surface | Anti-glare |
| Panel Technology | Thin Film Transistor (TFT) |
| Response Time | 29 ms |
| Aspect Ratio | 16:10 |
| Horizontal Viewing Angle | 170° |
| Vertical Viewing Angle | 170° |
| Mount Type | Rear Mount |
| Placement | Tabletop |
| Backlight Technology | LED |
| Features |
|
| Horizontal Frequency | 31.50 kHz to 80 kHz |
| Vertical Frequency | 60 Hz |
| Curved Screen | No |
| Video | |
|---|---|
| Maximum Resolution | 1280 x 800 |
| Standard Refresh Rate | 60 Hz |
| Color Supported | 262,000 Colors |
| Native Contrast Ratio | 800:1 |
| Brightness | 350 Nit |
| Maximum Refresh Rate | 60 Hz |
| Audio | |
|---|---|
| Speakers | Yes |
| Number of Speakers | 2 |
| Speaker Output Power | 4 W |
| Touchscreen Information | |
|---|---|
| Touchscreen | Yes |
| Touchscreen Type | TouchPro Projected Capacitive |
| Multi-touch Screen | Yes |
| Number of Simultaneous Touchpoints | 10 |
| Interfaces/Ports | |
|---|---|
| HDMI | Yes |
| USB | Yes |
| VGA | Yes |
| USB Type-C | Yes |
| Number of USB Ports | 4 |
| Total Number of USB Type-C Ports | 1 |
| Built-in Devices | |
|---|---|
| Built-in Devices | USB Hub |
| Power Description | |
|---|---|
| Operating Power Consumption | 7.43 W |
| Standby Power Consumption | 1.26 W |
| Off-Mode Power Consumption | 200 mW |
| Physical Characteristics | |
|---|---|
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 75 x 75 |
| Color Family | Black |
| Product Color | Black |
| Height | 7" |
| Width | 10" |
| Depth | 1.1" |
| Weight (Approximate) | 1.95 lb |
| Miscellaneous | |
|---|---|
| Package Contents |
|
| Mean Time Between Failures (MTBF) | 5.7 Year |
| Country of Origin | China |
| Environmentally Friendly | Yes |
| Environmental Compliance |
|
| Warranty | |
|---|---|
| Limited Warranty | 3 Year |
