Bixolon

BIX.HARDWARE.THERMAL PRINTERS..

SKU:

SRP-S3000XWDK

Barcode Label Printers, Bixolon SRP-S3000, 3" Sticky Label Media & Lined Label Printer, Black, Color LCD, 203 dpi USB/RS-232 Serial/Ethernet/Wi-Fi, Included Power Cord, USB Cable, Partition (2), Install Guide, Warranty-1 Year
Description
ico-plus ico-minus
Bixolon SRP-S3000 is a high-performance 3-inch linerless barcode label printer designed for various industries such as retail, healthcare, restaurants, and coffee shops. With its exceptional LinerlessPro™ technology, this printer ensures smooth operation and reduces waste, allowing you to print efficiently without the hassle of traditional labels. Its mobile-friendly design and user-centric features enhance productivity while offering versatile media options and superb print quality at speeds of up to 200 mm/sec.

Key features:
  • Specialized for Linerless Extreme and Restick media
  • Class-leading print speed of 200mm/sec
  • Easy, tool-less replacement of parts
  • Automatic guillotine cutting system
  • IP23 rating for water-resistant operation

Specifications:
  • Print Method: Direct Thermal (Front Exit)
  • Print Speed: Up to 200mm/sec
  • Print Resolution: 203 dpi
  • Media Type: Linerless Extreme, Restick, Liner Label
  • Media Width: 40/58/80 mm
  • Dimensions: 144 x 158 x 210 mm
  • Weight: 2.00 kg (4.40 lbs.)
  • Display: 2 inch Colour TFT LCD
  • Interface: USB V2.0 HS + Ethernet + Serial
  • Operating Temperature: 0~40°C
  • Humidity: 10~80% RH

Main Features

  • Equipment Format: Desktop

  • Case color: Black

  • Connection: Serial, USB, Ethernet

  • Printing Technology: Direct Thermal

Technical Specifications
ico-plus ico-minus
Technical Information
Recommended Use Label Print
Print Color Capability Monochrome
Maximum Mono Print Speed 7.87 in/s
Maximum Print Resolution (dpi) 203
Maximum Print Width 2.83"
Barcode Symbology Supported
  • Codabar
  • Code 39
  • Code 93
  • Code 128
  • EAN-13
  • EAN-8
  • ITF
  • UPC-A
  • UPC-E
  • Data Matrix
  • PDF417
  • QR Code
  • Code 11
  • Interleaved 2 of 5
  • LOGMARS
  • MSI
  • Plessey
  • POSTNET
  • GS1 DataBar
  • RSS-14
  • Standard 2 of 5
  • UPC/EAN
  • IMB
Application/Usage Desktop
Features Water Resistant
Character Sets
  • 95 Alphanumeric
  • 128 x 35 Graphic
  • 32 International
Connectivity Technology Wired
Fonts Included
  • Font A: 12 x 24
  • Font B: 9 x 17
  • Font C: 9 x 24
  • KOR: 24 x 24
  • CHN: 24 x 24
  • JPN: 24 x 24
Print Technology Direct Thermal
Memory
Standard Memory 128 MB
Interfaces/Ports
Serial Port Yes
USB Host Yes
USB Yes
Network & Communication
Ethernet Yes
Ethernet Technology Ethernet
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11a/b/g/n
Display & Graphics
Display Screen Yes
Screen Size 2"
Display Screen Type LCD
Media Types & Handling
Media Type
  • Label
  • Linered Media
  • Gap
  • Black Mark
  • Notch
  • Continuous Label
Media Sensor
  • Paper End Sensor
  • Black Mark Sensor
  • Cover Open Sensor
  • Gap Sensor
Media Thickness 5.91 mil
Maximum Roll Diameter 4.06"
Maximum Label Width 3.15"
Fonts & Emulation
Language Emulation
  • BXL/POS
  • SLCS
  • BPL-Z
  • BPL-C
Software
Operating System Supported Windows Driver, OPOS / JPOS Driver, Linux / Mac CUPS Driver, Virtual COM USB/Ethernet Driver, Utility Program
Software Included SDK / Plugin Android / iOS / Windows SDK, Linux SDK, Xamarin SDK, Chrome SDK, Web Print SDK Cordova Plugin
Power Description
Power Source Power Adapter
Environmental Conditions
Operating Temperature 32°F (0°C) - 104°F (40°C)
Operating Relative Humidity 10% - 80%
Storage Temperature -4°F (-20°C) - 140°F (60°C)
Storage Relative Humidity 10% - 90%
Physical Characteristics
Color Family Black
Product Color Black
Height 8.3"
Width 5.7"
Depth 6.2"
Weight (Approximate) 4.41 lb
Miscellaneous
Platform Supported
  • PC
  • iOS
  • Android
  • Mac
Energy Star Yes
Documents
ico-plus ico-minus
Product document srp-s3000.pdf SRP-S3000XWDK Product document srp-s300.pdf MOD-SRP-S300
