Datalogic

Datalogic PowerScan PBT9600-DPX Barcode Scanner, Direct Part Marking, Bluetooth, Removable Battery, Cordless, Industrial Handheld

SKU:

PBT9600-DPXRBK10US

Inductive wireless charging — which eliminates the battery contacts and pins prone to fouling or damage in industrial environments — sets the Datalogic PBT9600-DPXRBK10US apart within the PowerScan 9600 DPX family. The scanner's 1280 x 800 area imager reads Direct Part Marking codes produced by laser etching, dot peening, inkjet printing and electrochemical etching, resolving DataMatrix elements from 5 mil to 10 mil at a minimum print contrast of 15%, across a scanning distance of 8.90 in. Reading angles span 52 degrees skew, 52 degrees pitch and 360 degrees roll, and the imager operates under ambient light to 100000 lux. The removable 3350 mAh Li-Ion battery recharges in 3.20 hours, and Bluetooth 5.0 supports cordless operation with RS-232, USB, Ethernet and other interface options through the modular base. IP67 and IP65 ratings, 20kV air electrostatic discharge tolerance and a drop specification of 50 drops from 2.5 m at 20 degrees C cover the physical demands of manufacturing, assembly line and component-tracking deployments, with an operating range of -4 degrees F (-20 degrees C) to 122 degrees F (50 degrees C). The kit ships with scanner, cradle, cable, power supply and power cord.
Prices could not be updated.
Description
ico-plus ico-minus

The Datalogic Durablite 9600 is a rugged handheld data-capture solution designed for industrial, warehousing, logistics and field-service environments that require reliable hybrid reading. Combining UHF RFID read/write capability with a high-performance 2D imager, OCR/document capture and image acquisition, this cordless scanner enables inventory, asset tracking and verification workflows with a single device. Its removable 3350 mAh Li‑Ion battery with wireless charging options, bright OLED display, configurable keypads and broad connectivity (Bluetooth 5.0, USB, RS‑232, industrial Ethernet and more) deliver extended uptime, flexible integration and robust operation under IP65/IP67 protection and elevated drop resistance for demanding workflows.

Key Features

  • Hybrid data capture: Integrated UHF RFID reading/writing plus fast 2D imaging and OCR/document capture for consolidated tag and barcode workflows.
  • Rugged design: IP65/IP67 ingress protection and enhanced drop resistance for dependable operation in harsh industrial and logistics environments.
  • Extended runtime & serviceability: Removable 3350 mAh Li‑Ion battery with wireless charging support to minimize downtime and enable quick field swaps.
  • Broad connectivity: Bluetooth 5.0 wireless plus multi‑interface support (USB, RS‑232, USB‑C, Ethernet/Industrial Ethernet, Profinet) for flexible system integration.
  • Operator usability: High‑visibility OLED display and configurable key options (4‑key or 16‑key) with vibration/3GL feedback for clear on‑device interaction and confirmations.

Specifications

  • Brand: Datalogic
  • Product name: Durablite 9600
  • Category: Handheld Barcode Scanners
  • Color: Black, Blue
  • Weight: 415 g / 455 g
  • Dimensions: 19.8 x 15.0 x 7.9 cm
  • Form Factor: Handheld (rugged)
  • Reading mode / Scan technology: 2D imager (including high density and dual‑sensor options)
  • Supported codes: 1D, 2D, stacked codes, postal codes, Direct Part Marking (DPM)
  • OCR / Document Capture: true
  • Display: 1.8 in high‑visibility OLED (graphic)
  • Keypad / Function keys: Options: 4‑keys or 16 configurable keys
  • Battery: Li‑Ion, 3350 mAh (removable)
  • Scans per Charge (approx.): 80000 scans
  • Wireless charging: true
  • Connectivity / Interfaces: Bluetooth 5.0, USB, USB‑C, RS‑232, Ethernet, industrial Ethernet / protocols (Ethernet/IP, Profinet)
  • Bluetooth range: 100 m
  • RFID UHF frequency: 865–868 MHz
  • Ingress Protection: IP65, IP67
  • Drop Resistance: up to 2.5 m
  • Motion sensing: Motionix
  • Good‑read feedback: 3 Green Lights (3GL) and loud beeper
  • Trigger durability: 10,000,000 cycles

Main Features

  • Rugged: Industrial

  • Case color: Black

  • IP Rating: IP67

  • Range: Direct Part Mark

  • Connectivity: Cordless

  • Connection: RS232, Ethernet, Bluetooth, USB

  • Scanner Capability: 2D, DPM

  • Included Battery: Yes

  • Battery Features: Wireless Charging

Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Wireless
Scanning Capability
  • 1D
  • 2D
Barcode Symbology Supported

1D:

  • Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes.

2D:

  • Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code; Dot Code

Postal Codes:

  • Australian Post; British Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Postnet; Royal Mail Code (RM4SCC)

Stacked Codes:

  • EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites

Digital Watermarking:

  • Digimarc Barcodes (HP and DC models)
Light Source LED
Image Sensor Type Imager
Scan Mode Trigger
Scan Pattern Area
Scanner Range Standard Range
Scanning Distance 8.90"
Features
  • Ergonomic Design
  • Beep
  • Vibration
  • Notification LED
  • 3GL
Reading Angle (Skew) 52°
Reading Angle (Pitch) 52°
Reading Angle (Roll) 360°
Maximum Ambient Light 100000 lux
Drop Specification
  • Withstands 50 drops from 2.5 m / 8.2 ft @ 20 °C / 68 °F
  • Withstands 50 drops from 2.0 m / 6.6 ft @ -20 °C / -4 °
Minimum Print Contrast 15%
Minimum Element Resolution (DataMatrix) 5 mil
Maximum Element Resolution (DataMatrix) 10 mil
Direct Part Marking (DPM) Decoding Yes
Image Sensor Resolution 1280 x 800
Illumination Type LED
Illumination Color White
Air Electrostatic Discharge (+/-) 20kV
Network & Communication
Bluetooth Yes
Radio Frequency Yes
Interfaces/Ports
Host Interface USB
Power Description
Power Supply Included Yes
Battery Information
Battery Chemistry Lithium Ion (Li-Ion)
Battery Capacity 3350 mAh
Maximum Battery Recharge Time 3.20 Hour
Environmental Conditions
Operating Temperature -4°F (-20°C) to 122°F (50°C)
Storage Temperature -40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing) 0% to 95%
Physical Characteristics
Form Factor Handheld
Rugged Yes
Color Family Black
Product Color Black
Durability
  • Water Resistant
  • Dust Resistant
  • Drop Resistant
Height 7.8"
Width 3.1"
Length 5.9"
Weight (Approximate) 15.33 oz
Miscellaneous
Ingress Protection (IP) Rating
  • IP67
  • IP65
Application/Usage
  • Industrial
  • Manufacturing
  • Inventory
  • Assembly Line
  • Component Tracking
Documents
ico-plus ico-minus
Product document powerscan9600.pdf PBT9600-DPXRBK10US  (PDF)
