Zebra

Zebra ZQ61-AUX2004-00 Label Printers

SKU:

ZQ61-AUX2004-00

Duplex direct thermal printing at up to 4.53 in/s sets the Zebra ZQ61-AUX2004-00 apart within the ZQ610 Plus family, delivering monochrome label and receipt output at 203 dpi across a 1.90-inch print width, with maximum label lengths to 32 inches and roll diameter to 2.20 inches. Media thickness capacity reaches 5.50 mil, and the printer handles gap, die-cut, linerless, black mark, tag, and receipt stock, with gap, black mark, and label present sensors managing detection. Wireless LAN, Bluetooth, and NFC cover connectivity, while 256 MB of standard memory supports ZPL, EPL, and CPCL emulation alongside iOS, Android, and PC platform compatibility. The IP54-rated portable chassis weighs 1.33 lb and operates from 4°F (-15.6°C) to 122°F (50°C), spanning retail, warehouse, transportation, logistics, and manufacturing applications. Energy Star qualified and backed by a one-year limited warranty.
Prices could not be updated.
Description
ico-plus ico-minus
The Zebra ZQ610 Plus is a mobile direct thermal label and receipt printer built for field workers, store associates, and warehouse operators who need reliable on-the-spot printing throughout a full shift. Producing monochrome output at 203 dpi and up to 4.5 in./115 mm per second across a maximum print width of 1.9 in./48 mm, it delivers crisp barcodes, text, and graphics at the point of service. Bluetooth connectivity, NFC, and optional Wireless LAN keep it integrated with iOS, Android, and PC environments, while the 3250 mAh PowerPrecision+ Li-Ion battery sustains continuous operation across long shifts. An IP54-rated housing with drop tolerance to 5 ft./1.52 m to concrete suits the demands of retail, warehousing, transportation and logistics, and healthcare workflows. The Link-OS operating system, ZPL, EPL, and CPCL language emulations, and compatibility with Zebra Print DNA tools simplify deployment and remote management for IT teams.

Main Features

  • Equipment Format: Mobile

  • Connection: Bluetooth

  • Printing Technology: Direct Thermal

Technical Specifications
ico-plus ico-minus
Technical Information
Recommended Use Label/Receipt Print
Print Color Capability Monochrome
Printing Capability Double Sided
Maximum Mono Print Speed 4.53 in/s
Maximum Print Resolution (dpi) 203
Maximum Print Length 32"
Maximum Print Width 1.90"
Barcode Symbology Supported
  • Code 39
  • Code 93
  • TLC 39
  • Code 128
  • QR Code
  • Data Matrix
  • 2 and 5 Digits Add-on
  • EAN-8
  • EAN-13
  • PDF417
  • Codabar (NW-7)
  • 2D
  • Micro PDF-417
  • Maxi Code
  • FIM Postnet
  • AZTEC
  • GS1 DataBar (RSS)
  • MSI PLESSEY
  • Interleaved 2 of 5
  • UPC-A
  • UPC-E
  • UCC/EAN 128
Application/Usage
  • Retail
  • Transportation & Logistic
  • Manufacturing
  • Mobile
  • Warehouse
Features
  • Dust Resistant
  • Water Resistant
Mobile Device Printing Yes
Ingress Protection (IP) Rating IP54
Connectivity Technology Wireless
Duplex Printing Yes
Print Technology Direct Thermal
Memory
Standard Memory 256 MB
Network & Communication
Bluetooth Yes
Wireless LAN Yes
Near Field Communication (NFC) Yes
Media Types & Handling
Media Type
  • Gap
  • Tag
  • Label
  • Receipt
  • Die-cut Label
  • Linerless Label
  • Black Bar
  • Black Mark
Media Sensor
  • Black Mark Sensor
  • Gap Sensor
  • Label Present Sensor
Media Thickness 5.50 mil
Maximum Roll Diameter 2.20"
Maximum Label Width 2.20"
Maximum Label Length 32"
Fonts & Emulation
Language Emulation
  • CPCL
  • EPL
  • ZPL
Software
Operating System Supported
  • Link-OS
Power Description
Power Source Battery
Environmental Conditions
Operating Temperature 4°F (-15.6°C) - 122°F (50°C)
Operating Relative Humidity 10% - 90%
Storage Temperature 13°F (-10.6°C) - 149°F (65°C)
Storage Relative Humidity 10% - 90%
Physical Characteristics
Form Factor Portable
Height 2.9"
Width 3.6"
Depth 6.7"
Weight (Approximate) 1.33 lb
Miscellaneous
Platform Supported
  • iOS
  • Android
  • PC
Energy Star Yes
Warranty
Limited Warranty 1 Year
Documents
ico-plus ico-minus
Product document zq600-series.pdf ZQ61-AUX2004-00  (PDF)
