Honeywell

Honeywell HF811 Escáner de códigos de barras 2D, Area Imager, DPM, RS232, Ethernet, IP65

SKU:

HF811-01BT00004K-R

Honeywell Pro 2D is a compact fixed-mount 2D area imager barcode scanner built for industrial applications. Its black, built-in form factor supports 1D and 2D codes, including QR, DataMatrix, MaxiCode, Aztec, PDF417, and DPM, while the wide depth of field, blue illumination, IP65 protection, and network-ready connectivity help it fit demanding workflows with dependable performance.
Description
ico-plus ico-minus

The Honeywell DataMax 810/811 is a compact fixed‑mount barcode scanner family engineered for industrial and automation environments that require reliable, continuous data capture. Designed as an area imager for built‑in installations, these scanners deliver 2 MP image resolution and wide‑angle optics to read 1D, 2D and Direct Part Mark (DPM) codes across manufacturing, logistics, packaging and sorting applications. Variants offer options such as liquid‑lens fast autofocus, selectable white or blue illumination, and rugged IP65 protection, enabling straightforward integration with Ethernet, RS232 and RS485 hosts while providing consistent decoding performance across varied working distances and lighting conditions.

Key Features

  • Fixed‑mount form factor: Compact, built‑in design for installation in conveyor, sorting and production line stations where space and stability are required.
  • Reliable 1D/2D and DPM decoding: Native support for common symbologies plus Direct Part Marking to handle marked components and challenging codes.
  • 2 MP area imager with wide field of view: High‑resolution imaging and wide‑angle optics improve read rates and reduce the need for precise alignment.
  • Industrial connectivity: Ethernet, RS232 and RS485 interfaces (with extended options such as TCP/IP, Profinet and Modbus TCP on some variants) simplify integration into automation and PLC systems.
  • Rugged IP65 construction: Ingress protection suitable for dusty and wet industrial environments, supporting dependable continuous operation.
  • Deployment flexibility: Options like liquid lens autofocus, selectable illumination (white/blue), auto‑tune and I/O support ease commissioning and improve performance across use cases.

Specifications

  • Brand: Honeywell
  • Product family / Model: DataMax 810/811 (HF811)
  • Form Factor: Fixed‑mount
  • Imaging Type: Area imager
  • Image Resolution: 2 MP
  • Lens Type: Liquid Lens (available on some variants)
  • Scan Capability: 1D and 2D; DPM supported
  • Supported Symbologies: QR, DataMatrix, MaxiCode, Aztec, PDF417, 1D
  • Field of View: Wide angle
  • Depth of Field: 0 – 1000 mm
  • Illumination Color: White / Blue (variant dependent)
  • Connectivity / Interfaces: Ethernet, RS232, RS485 (some variants also list TCP/IP, Profinet, EthernetIP, Modbus TCP)
  • Ingress Protection (IP) Rating: IP65
  • Operating Temperature: 0°C to 50°C (on select variants)
  • Dimensions (example variant): 70 x 55 x 45 mm (variant dependent)
  • Weight (example variant): 180 g / 6.35 oz (variant dependent)

Main Features

  • Rugged: Industrial

  • Connection: Ethernet, Serial, RS232

  • Scanner Capability: 2D, Imager

Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Cable
Scanning Capability
  • 1D
  • 2D
Barcode Symbology Supported
  • Reads standard 1D
  • PDF
  • 2D (QR, Datamatrix, Maxicode, Aztec)
  • DPM
Image Sensor Type Imager
Field of View (Horizontal) 20°
Field of View (Vertical) 11°
Maximum Ambient Light 100000 lux
Direct Part Marking (DPM) Decoding Yes
Interfaces/Ports
Host Interface
  • Serial
  • Ethernet
Physical Characteristics
Form Factor Fixed Mount
Product Color Black
Height 2.8"
Width 2.2"
Depth 1.8"
Weight (Approximate) 6.35 oz
Miscellaneous
Ingress Protection (IP) Rating IP65
Application/Usage
  • Industrial
  • Warehouse
  • Manufacturing
Warranty
Limited Warranty 3 Year
Documents
ico-plus ico-minus
Product document hf81x-2022.pdf HF811-01BT00004K-R Product document hf81x-2022.pdf MOD-HF811
FAQs
ico-plus ico-minus
What barcode symbologies can the Honeywell HF811 read, and does it support Direct Part Marking?
The HF811 reads both 1D and 2D symbologies, including QR Code, DataMatrix, MaxiCode, Aztec, and PDF417, and it natively supports Direct Part Mark (DPM) codes for reading marked components common in manufacturing and industrial settings.
What interfaces does the Honeywell HF811 support for integrating with automation or PLC systems?
The HF811 offers Ethernet, RS232, and RS485 connectivity, with certain variants also supporting TCP/IP, Profinet, EtherNet/IP, and Modbus TCP for broader integration into industrial automation and PLC environments.
What is the ingress protection rating of the Honeywell HF811, and what environments is it suited for?
The HF811 carries an IP65 rating, making it resistant to dust and water ingress and suitable for continuous operation in demanding industrial settings such as conveyor lines, sorting stations, and packaging environments.
What is the imaging resolution and depth of field of the Honeywell HF811?
It uses a 2 MP area imager with a wide-angle field of view and a depth of field ranging from 0 to 1000 mm, reducing the need for precise alignment during installation.
How is the Honeywell HF811 configured and optimized after installation?
The HF811 supports setup through the DataMax Plus configuration tool and includes an Autotune function that automatically optimizes scanning parameters with the press of a button, simplifying commissioning on the line.
