Elo Slate ESY15I4 Touch Terminal 15.6", 1920 x 1080, 10-touch, 4GB, 32GB, RK3399

SKU:

E240416

At just 0.9 inch thick and 3.53 lb, the Elo E240416 is an all-in-one POS terminal built around a 15.6-inch LED display running at 1920 x 1080 with a 700:1 contrast ratio, 160-degree horizontal and vertical viewing angles, and a 20 ms response time. The projected capacitive touchscreen supports 10 simultaneous touch points, while the hexa-core Rockchip RK3399 processor pairs with 4 GB of RAM and 32 GB of flash storage to handle checkout and order-entry workloads under Linux. A microSD slot extends storage, and connectivity spans Gigabit Ethernet, Wi-Fi, Bluetooth 5.0, USB Type-C, one USB 3.0 port, and four Micro USB 2.0 ports, with an included I/O hub extending peripheral reach. The integrated webcam captures at 1920 x 1080 at 30 fps, and dual 2 W speakers support audio output. The dark gray metallic chassis measures 15.3 in wide by 9.8 in deep and ships with a 65 W power brick; a two-year limited warranty is included.
Prices could not be updated.
Description
ico-plus ico-minus

The Elo Interactive is a family of Elo I-Series all‑in‑one touch computers engineered for commercial and enterprise deployments such as retail POS, self‑service kiosks, hospitality terminals, and clinical or corporate workstations. Combining projected capacitive multi‑touch with Full HD displays, rugged edge‑to‑edge glass, and a range of processor and OS options, the line delivers responsive user interaction, flexible I/O and networking, and compact integration for countertop or kiosk mounting. Available configurations support different performance and storage needs—ranging from low‑power ARM and Celeron platforms to high‑performance Core i5 and Rockchip RK3399 options—enabling tailored deployments that balance speed, reliability, and total cost of ownership.

Key Features

  • Precise multi‑touch interaction: Projected capacitive touch with 10 simultaneous touch points for accurate, fast input across retail, kiosk, and clinical workflows.
  • Full HD commercial displays: 1920 x 1080 IPS/TFT panels with edge‑to‑edge or clear glass surfaces that provide vibrant visuals and wide viewing angles for customer‑facing applications.
  • Flexible performance options: Multiple processor and OS configurations (Qualcomm Snapdragon, Rockchip RK3399, Intel Celeron, Intel Core i5; Android, Windows 10 IoT, Debian Linux) to meet specific application and management requirements.
  • Comprehensive connectivity: Built‑in Ethernet (Gigabit), Wi‑Fi (including 802.11ac), Bluetooth, optional cellular (4G), HDMI and multiple USB/MicroSD options for peripherals and networked deployments.
  • Commercial reliability and deployment flexibility: Durable designs with high MTBF, VESA mounting options and multiple form factors (15.6" and 21.5") for countertop, wall or kiosk integration.

Specifications

  • Brand: Elo
  • Product family / Reference: Elo I-Series Touch Computers / Elo Interactive TouchPro
  • Category: All in One
  • Touch technology: Projected Capacitive
  • Touch points: 10
  • Display resolution: 1920 x 1080
  • Available diagonal sizes: 15.6 in, 21.5 in
  • Display types: IPS / TFT / Widescreen LED
  • Bezel style: Zero‑bezel, edge‑to‑edge glass / Clear Glass
  • Processor options: Qualcomm Snapdragon ARM A15; Rockchip RK3399; Intel Celeron series; Intel Core i5
  • Operating systems: Android; Windows 10 IoT Enterprise; Debian Linux 10
  • RAM (typical configurations): 2 GB, 4 GB (expandable on select models)
  • Internal storage (typical): 16 GB eMMC; 32 GB Flash; 128 GB SSD
  • Storage types: eMMC, Flash, SATA SSD
  • Connectivity: Bluetooth, Ethernet (10/100/1000), Wi‑Fi (including 802.11ac), Cellular (4G on select models), HDMI
  • Micro SD / memory card: microSD slot (available on select models)
  • Audio & multimedia: Integrated speakers and audio I/O; some models include integrated webcams and microphone input
  • VESA mount: 100 x 100 mm (select models)
  • MTBF: 50,000 h (select models)
  • Weight (varies by model): approx. 1.3 kg – 4.3 kg
  • Mounting orientations: Portrait, landscape, table‑top

Main Features

  • Touch: Yes

  • POS: Yes

  • Screen size: 16 inch

  • Connection: Ethernet, USB

  • Screen type: Capacitve

Technical Specifications
ico-plus ico-minus
Technical Information
Bluetooth Yes
Bluetooth Standard Bluetooth 5.0
Form Factor All-in-One
Processor & Chipset
Processor Core Hexa-core (6 Core)
Processor Model RK3399
Memory
Standard Memory 4 GB
Memory Card Slot Yes
Memory Card Supported microSD
Storage
Flash Memory Capacity 32 GB
Display & Graphics
Screen Size 15.6"
Active Display Size (Horizontal) 13.55"
Active Display Size (Vertical) 7.62"
Display Screen Type LED
Touchscreen Yes
Touchscreen Technology Projected Capacitive
Multi-touch Screen Yes
Number of Simultaneous Touch Points 10
Aspect Ratio 16:9
Contrast Ratio 700:1
Response Time 20 ms
Color Supported 16.7 Million Colors
Horizontal Viewing Angle 160°
Vertical Viewing Angle 160°
Network & Communication
Wireless LAN Yes
Ethernet Technology Gigabit Ethernet
Interfaces/Ports
USB Yes
USB Type-C Yes
Network (RJ-45) Yes
Number of Micro USB 2.0 Ports 4
Number of USB 3.0 Ports 1
Built-in Devices
Webcam Frame Rate 1920 x 1080 @ 30 fps
Number of Speakers 2
Speaker Power 2 W
Software
Operating System Linux
Power Description
Power Source AC Power
Physical Characteristics
Color Family Gray
Product Color Dark Gray Metallic
Height 0.9"
Width 15.3"
Depth 9.8"
Weight (Approximate) 3.53 lb
Miscellaneous
Package Contents
  • I-Series POS Terminal
  • I-Series Slate
  • IO Hub
  • North American Power Cable
  • European Power Cable
  • 1x Power Brick 65W (E153026)
  • Quick Install Guide
  • 4 x M4x6 mm Flathead screws in a plastic bag
  • 4 x M4x6 mm Panhead screws in a plastic bag
Warranty
Limited Warranty 2 Year
