Elo

Elo 1523L, 15'', iTouch Plus, black

SKU:

E394454

Fitted with iTouch Plus surface acoustic wave multi-touch technology, the Elo E394454 is a 15-inch zero-bezel LCD touchscreen monitor in black, delivering a 25 ms response time and stable, drift-free operation across an anti-glare, anti-scratch screen surface. It resolves to 1024 x 768 at 60 Hz with 250 Nit brightness, a 700:1 contrast ratio, and 16.2 million colors across a 4:3 panel with 160-degree horizontal and 140-degree vertical viewing angles. Video connectivity spans DVI and VGA inputs, with USB and a built-in USB hub rounding out the interface set. The adjustable stand supports desk use and VESA 75 x 75 mounting for wall or pole installation, while the dual-voltage power supply accepts 110 V AC and 220 V AC at 12 W operating draw. The unit weighs 9.79 lb with stand and carries UL/cUL, FCC-A, CE, VCCI, Semko and C-Tick certifications, backed by a 3-year limited warranty.
Prices could not be updated.
Description
ico-plus ico-minus
The Elo 1523L is a 15-inch LCD touchscreen monitor designed for IT and procurement teams outfitting high-traffic retail, hospitality, and point-of-sale environments. Built around Elo's iTouch Plus Surface Acoustic Wave touchscreen technology, it delivers stable, drift-free multi-touch operation with a zero-bezel, anti-glare, anti-scratch glass surface that stands up to spills, impacts, and daily wear. The XGA panel resolves at 1024 x 768 with 250 Nit brightness and a 700:1 contrast ratio, while a 25 ms response time keeps interactions crisp and accurate. VGA, DVI, and USB connectivity — plus an integrated USB hub — simplify cabling alongside built-in cable management, and VESA 75 x 75 compatibility supports both desk and wall mounting. A 3-year limited warranty rounds out a monitor built to perform.

Main Features

  • Touch: Yes

  • Connection: USB

Technical Specifications
ico-plus ico-minus
Technical Information
Screen Size Class 15"
Viewable Screen Size 15"
Screen Surface
  • Anti-glare
  • Anti-scratch
Response Time 25 ms
Aspect Ratio 4:3
Horizontal Viewing Angle 160°
Vertical Viewing Angle 140°
Adjustable Display Angle Yes
Adjustable Display Height Yes
Mount Type
  • Desk Mountable
  • Wall Mountable
Features
  • Security Lock
  • Water Proof
  • Cable Management
Adjustable Stand Yes
Video
Maximum Resolution 1024 x 768
Standard Refresh Rate 60 Hz
Color Supported 16.2 Million Colors
Contrast Ratio 700:1
Brightness 250 Nit
Audio
Speakers Yes
Touchscreen Information
Touchscreen Yes
Touchscreen Type Surface Acoustic Wave
Multi-touch Screen Yes
Interfaces/Ports
DVI Yes
USB Yes
VGA Yes
Built-in Devices
Built-in Devices USB Hub
Power Description
Input Voltage
  • 110 V AC
  • 220 V AC
Operating Power Consumption 12 W
Physical Characteristics
VESA Mount Compatible Yes
VESA Mount Standard 75 x 75
Color Family Black
Product Color Black
Height with Stand 7.83"
Width with Stand 14.09"
Depth with Stand 12.52"
Weight (Approximate) 5.84 lb
Weight with Stand (Approximate) 9.79 lb
Miscellaneous
Package Contents
  • 1523L Multifunction 15-Inch Desktop Touchmonitor
  • Touch Cables
  • Video Cables
Certifications & Standards
  • UL/cUL
  • FCC-A
  • Semko
  • CE
  • VCCI
  • C-Tick
Platform Supported PC
Warranty
Limited Warranty 3 Year
Documents
ico-plus ico-minus
Product document 1532l-2021.pdf E394454
FAQs
ico-plus ico-minus
What display size and native resolution does the Elo 1523L Touchscreen offer?
The Elo 1523L features a 15-inch LCD panel with a native resolution of 1024 x 768 and a 4:3 aspect ratio, delivered via an active matrix TFT LCD with LED backlighting.
How many simultaneous touch points does the Elo 1523L support, and what touch technology does it use?
The Elo 1523L supports up to 10 simultaneous touch interactions using Surface Acoustic Wave touch technology, which provides drift-free operation with resistance to water, impacts, and scratches.
Can the Elo 1523L be wall-mounted, and what VESA standard does it follow?
Yes, the Elo 1523L is VESA mount compatible using the 75 x 75 mm standard, allowing installation on walls or compatible stands.
What integrated peripherals can the Elo 1523L accommodate beyond standard display use?
The Elo 1523L includes integrated options for a magnetic stripe reader, NFC/RFID reader, and webcam, making it suitable for full point-of-service deployments in retail and hospitality environments.
What warranty does the Elo 1523L carry, and what is included in the box?
The Elo 1523L comes with a 3-year limited warranty and is packaged with the touchmonitor itself, touch cables, and video cables.
What are the brightness and contrast specifications of the Elo 1523L Touchscreen?
The Elo 1523L delivers a brightness of 250 nits and a contrast ratio of 700:1, supporting up to 16.2 million colors for clear image rendering in high-traffic environments.
