Custom KPM180H-LL Ticket Printer Linerless, 20 - 82.5 mm, >203 mm/s, 60 - 255 g/m2, 1000000 cuts, RS232/USB/Ethernet

The Nano from Custom is a compact, professional thermal receipt and ticket printer built for POS, kiosk and self-service environments where space, speed and reliability are essential. Designed to handle roll, fan-folded and linerless media, it supports adjustable paper widths from 20 to 82.5 mm and is offered in configurations that deliver 200, 203 or 300 dpi output for clear receipts, tickets and barcode printing. With wired RS232/USB/Ethernet interfaces and optional Wi‑Fi/Bluetooth, the unit integrates easily into retail, transport, events and hospitality workflows. Key benefits include fast throughput to reduce queues, flexible media compatibility and low-maintenance thermal operation for business-critical deployments.

Key Features

• Ultra-compact footprint: Small form factor designed for tight counter and kiosk installations, simplifying OEM integration and space-constrained deployments.
• Fast thermal printing: High-speed thermal output (200 mm/s–>203 mm/s and up to 150 mm/s at 300 dpi) accelerates transaction times and ticket throughput.
• Flexible media handling: Supports roll, fan-folded and linerless media with adjustable widths from 20 to 82.5 mm and broad paper thickness compatibility.
• Versatile connectivity: Standard RS232, USB and Ethernet interfaces with optional Wi‑Fi and Bluetooth provide straightforward integration into diverse POS and kiosk systems.
• Integrated finishing options: Configurable cutter, presenter and tear-off functions (and long-life cutter options) streamline ticket delivery and reduce manual handling.

Specifications

• Brand: Custom
• Product Reference: Custom KPM180H Receipt Printer
• Print Technology: Thermal (direct/fixed head)
• Print Resolution: 200 dpi, 203 dpi or 300 dpi
• Print Speed: >203 mm/s; 200 mm/s (200 dpi) / 150 mm/s (300 dpi)
• Printing Width: 80 mm (maximum printing width where specified)
• Paper Width Range: 20 - 82.5 mm
• Supported Paper Types: Roll, fan-folded, linerless
• Paper Thickness Range: 60 - 255 g/m² (variants may specify 70 - 255 g/m²)
• Maximum Paper Thickness: 270 µm
• Interfaces: RS232, USB, Ethernet
• Connectivity Options: Wi‑Fi, Bluetooth (optional)
• Integrated Cutter: Available (configurable; cutter life up to 1,000,000 cuts)
• Linerless Support: Supported on select configurations
• Internal Flash Memory: Values reported per variant (examples: 1 MB, 3 MB, 5 MB)
• RAM / Data Buffer: 128 KB internal + external options; 16 KB data buffer
• Supported Barcodes: 1D and 2D including UPC, EAN, CODE39, CODE128, PDF417, DataMatrix, Aztec, QR Code
• Emulation: CUSTOM/POS, SVELTA
• Print Head Life: 100 km (approximately)
• MTBF (electronic board): 113,000 hours
• Cutter Life: 1,000,000 cuts (where fitted)
• Dimensions (variant dependent): 97.5 x 67 x 108 mm or 149.5 x 67 x 108 mm
• Weight: 0.8 kg
• Operating Temperature Range: -10 to 60 °C
• Power Supply: 24 VDC ±10%
