Zebra

RTL10B1-H4AS0X0000NA

SKU:

RTL10B1-H4AS0X0000NA

Running Android 11 on a Qualcomm Snapdragon 660 chipset with a Kryo 260 octa-core processor clocked at 2.20 GHz, the Xplore RTL10B1-H4AS0X0000NA is a slate-form rugged tablet built for demanding field and industrial environments. Its 10.1-inch View Anywhere display resolves at 1920 x 1200 WUXGA in a 16:10 aspect ratio, protected by Gorilla Glass 3 and rated for glove touch and wet touch input. Multi-constellation positioning spans A-GPS, GLONASS, Galileo and Beidou, while wireless connectivity covers IEEE 802.11a/b/g/n/ac/d/h/i/r/k/w Wi-Fi and Bluetooth. The removable battery supports up to 9.80 hours of runtime, and the USB Type-C port provides USB 2.0, USB 3.0 and DisplayPort output. A 13 Megapixel auto-focus rear camera and 5 Megapixel front camera are built in alongside a 3-axis accelerometer, gyroscope, eCompass and ambient light sensor. At 2.70 lb with dimensions of 11.1 in tall, 7.7 in wide and 0.9 in deep, it carries EPEAT Silver certification, Energy Star qualification, RoHS 2 and WEEE compliance, and is backed by a 3-year limited warranty.
Prices could not be updated.
Description
ico-plus ico-minus
The Zebra XSLATE L10 is an industrial-grade 10.1-inch rugged tablet designed for mobile workers who operate in demanding field and indoor environments. Built for sectors including warehousing, manufacturing, field service, utilities, construction, oil and gas, and public safety, it supports both Android and Windows operating systems, giving IT teams the flexibility to deploy the platform that fits their enterprise stack. Bluetooth connectivity keeps the tablet integrated with wireless peripherals and enterprise systems, while optional GPS enables location-aware workflows for field teams and vehicle-mounted deployments. An IP65-sealed, MIL-STD-810G-tested enclosure with a 6 ft. drop specification and a lightweight magnesium alloy frame protects the device against water, dust, drops, and extreme temperatures, ensuring continuous productivity across shifts without sacrificing portability.

Main Features

  • Operation System: Android

  • Rugged: Industrial

  • GPS: Yes

  • Connection: Bluetooth

Technical Specifications
ico-plus ico-minus
Processor
Processor Type Kryo 260
Processor Speed 2.20 GHz
Processor Core Octa-core (8 Core)
Chipset
Chipset Manufacturer Qualcomm
Chipset Model Snapdragon 660
Memory
Memory Card Supported microSDXC
Display & Graphics
Screen Size 10.1"
Display Screen Technology View Anywhere
Aspect Ratio 16:10
Screen Mode WUXGA
Screen Resolution 1920 x 1200
Graphics Controller Model Adreno 512
Graphics Memory Accessibility Shared
Network & Communication
Wireless Connectivity Technology Wi-Fi
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11a/b/g/n/ac/d/h/i/r/k/w
Bluetooth Yes
Interfaces/Ports
USB Type-C Yes
USB Type-C Detail USB Type-C port (USB 2.0, USB 3.0, Display Port out)
Built-in Devices
Sensor Type
  • 3-axis Accelerometer
  • Ambient Light Sensor
  • Gyroscope
  • eCompass
Front Camera Yes
Front Camera Resolution 5 Megapixel
Rear Camera Yes
Rear Camera Resolution 13 Megapixel
Focus Modes Auto-focus
Operating System
Operating System Platform Android
Operating System Android 11
Battery Information
Removable Battery Yes
Maximum Battery Run Time 9.80 Hours
Power Description
Power Source AC Adapter
Physical Characteristics
Rugged Yes
Form Factor Slate
Height 11.1"
Width 7.7"
Depth 0.9"
Weight (Approximate) 2.70 lb
Miscellaneous
Package Contents
  • XSLATE L10 Tablet
  • AC Adapter
Features
  • Gorilla Glass 3
  • Glove Touch
  • Water Proof
  • Dust Proof
  • Drop Proof
  • GLONASS
  • Galileo
  • Beidou
  • Assisted GPS (A-GPS)
  • Removable Battery
  • Wet Touch
Energy Star Yes
Country of Origin Taiwan
Environmentally Friendly Yes
Environmental Certification Electronic Product Environmental Assessment Tool Silver (EPEAT Silver)
Environmental Compliance
  • Restriction of Hazardous Substances (RoHS) 2
  • Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty 3 Year
Documents
ico-plus ico-minus
Product document l10.pdf RTL10B1-H4AS0X0000NA  (PDF)
FAQs
ico-plus ico-minus
What ingress protection and drop ratings does the Zebra XSLATE L10 rugged tablet carry?
The XSLATE L10 is rated IP65 for dust and water resistance and is tested to MIL-STD-810G, including a 6 ft drop specification to plywood over concrete.
What wireless connectivity options are built into the Zebra XSLATE L10?
The XSLATE L10 includes Wi-Fi 5 (802.11ac), Bluetooth 4.2, NFC, and integrated GPS, with optional 4G LTE WWAN for mobile broadband connectivity.
What processor and memory does the Zebra XSLATE L10 ship with?
It is equipped with an Intel Core i5-8250U processor running at 1.6 GHz base frequency with a 3.4 GHz boost, paired with 8 GB of LPDDR3-SDRAM and a 128 GB SSD.
How long does the Zebra XSLATE L10 battery last, and can it be swapped without powering down the device?
The XSLATE L10 delivers up to 10 hours of typical battery life, extendable to over 24 hours with an extended battery option, and the battery is hot-swappable so the device stays in service during a swap.
What security features does the Zebra XSLATE L10 include for enterprise deployments?
The tablet includes a Trusted Platform Module (TPM) and an integrated fingerprint reader to control access to data and applications.
Which industries and use cases is the Zebra XSLATE L10 designed for?
The XSLATE L10 targets field service, logistics, utilities, manufacturing, public safety, and vehicle-mounted applications where a sunlight-readable display, rugged construction, and location-aware connectivity are required.
