Zebra

RTL10B1-B4AS0X0000NA

SKU:

RTL10B1-B4AS0X0000NA

Configured with 4 GB of RAM paired with 128 GB of flash storage, the Zebra RTL10B1-B4AS0X0000NA is a slate-form rugged Android tablet built around a Qualcomm Snapdragon 660 chipset running a Kryo 260 octa-core processor at 2.20 GHz, with microSDXC expansion supported. Its 10.1-inch WUXGA View Anywhere, anti-glare display resolves at 1920 x 1200 in a 16:10 aspect ratio, suited for use in bright outdoor conditions. Wireless connectivity spans IEEE 802.11ac Wi-Fi, 4G LTE with HSPA+ and GPRS/EDGE/UMTS, Bluetooth, NFC, and GPS with GLONASS, Galileo, and Beidou support, while a USB Type-C port carries USB 2.0, USB 3.0, and DisplayPort signaling. A 13 Megapixel auto-focus rear camera and 5 Megapixel front camera, Gorilla Glass 3, glove-touch input, and sensors including a 3-axis accelerometer, gyroscope, ambient light sensor, and eCompass round out the platform. Battery runtime reaches 9.80 Hours, and the 2.70 lb chassis is upgradable to Android 14. EPEAT Silver certified, RoHS 2 compliant, and Energy Star qualified, the RTL10B1-B4AS0X0000NA carries a 3 Year limited warranty.
Prices could not be updated.
Description
ico-plus ico-minus
The Zebra XSLATE L10 is an industrial-grade 10.1-inch rugged tablet designed for mobile workers who operate in demanding field and indoor environments. Built for sectors including warehousing, manufacturing, field service, utilities, construction, oil and gas, and public safety, it supports both Android and Windows operating systems, giving IT teams the flexibility to deploy the platform that fits their enterprise stack. Bluetooth connectivity keeps the tablet integrated with wireless peripherals and enterprise systems, while optional GPS enables location-aware workflows for field teams and vehicle-mounted deployments. An IP65-sealed, MIL-STD-810G-tested enclosure with a 6 ft. drop specification and a lightweight magnesium alloy frame protects the device against water, dust, drops, and extreme temperatures, ensuring continuous productivity across shifts without sacrificing portability.

Main Features

  • Operation System: Android

  • Rugged: Industrial

  • GPS: Yes

  • Connection: Bluetooth

Technical Specifications
ico-plus ico-minus
Processor
Processor Type Kryo 260
Processor Speed 2.20 GHz
Processor Core Octa-core (8 Core)
Chipset
Chipset Manufacturer Qualcomm
Chipset Model Snapdragon 660
Memory
Standard Memory 4 GB
Memory Card Supported microSDXC
Storage
Flash Memory Capacity 128 GB
Display & Graphics
Screen Size 10.1"
Display Screen Technology
  • View Anywhere
  • Anti-glare
Aspect Ratio 16:10
Screen Mode WUXGA
Screen Resolution 1920 x 1200
Graphics Controller Model Adreno 512
Graphics Memory Accessibility Shared
Network & Communication
WWAN Supported Yes
Wireless Connectivity Technology Wi-Fi + Cellular
SIM Size Supported Nano
Cellular Phone Capability Yes
Cellular Generation 4G
Cellular Data Connectivity Technology
  • GPRS
  • EDGE
  • LTE
  • UMTS
  • HSPA
  • HSPA+
GPS Yes
Wireless LAN Yes
Wireless LAN Standard IEEE 802.11ac
Bluetooth Yes
Near Field Communication Yes
Interfaces/Ports
USB Type-C Yes
USB Type-C Detail USB Type-C port (USB 2.0, USB 3.0, Display Port)
Built-in Devices
Sensor Type
  • 3-axis Accelerometer
  • Gyroscope
  • Ambient Light Sensor
  • eCompass
Front Camera Yes
Front Camera Resolution 5 Megapixel
Rear Camera Yes
Rear Camera Resolution 13 Megapixel
Focus Modes Auto-focus
Operating System
Operating System Platform Android
Upgradable Operating System Android 14
Battery Information
Maximum Battery Run Time 9.80 Hours
Physical Characteristics
Rugged Yes
Form Factor Slate
Height 11"
Width 7.7"
Depth 0.9"
Weight (Approximate) 2.70 lb
Miscellaneous
Features
  • Gorilla Glass 3
  • Glove Touch
  • Water Proof
  • Dust Proof
  • Drop Proof
  • Shock Proof
  • Vibration Resistant
  • GLONASS
  • Galileo
  • Beidou
  • Anti-Shock
Energy Star Yes
Environmentally Friendly Yes
Environmental Certification Electronic Product Environmental Assessment Tool Silver (EPEAT Silver)
Environmental Compliance
  • Battery Directive
  • Restriction of Hazardous Substances (RoHS) 2
  • Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty 3 Year
Documents
ico-plus ico-minus
Product document l10.pdf RTL10B1-B4AS0X0000NA  (PDF)
FAQs
ico-plus ico-minus
What ingress protection and drop ratings does the Zebra XSLATE L10 rugged tablet carry?
The XSLATE L10 is rated IP65 for dust and water resistance and is tested to MIL-STD-810G, including a 6 ft drop specification to plywood over concrete.
What wireless connectivity options are built into the Zebra XSLATE L10?
The XSLATE L10 includes Wi-Fi 5 (802.11ac), Bluetooth 4.2, NFC, and integrated GPS, with optional 4G LTE WWAN for mobile broadband connectivity.
What processor and memory does the Zebra XSLATE L10 ship with?
It is equipped with an Intel Core i5-8250U processor running at 1.6 GHz base frequency with a 3.4 GHz boost, paired with 8 GB of LPDDR3-SDRAM and a 128 GB SSD.
How long does the Zebra XSLATE L10 battery last, and can it be swapped without powering down the device?
The XSLATE L10 delivers up to 10 hours of typical battery life, extendable to over 24 hours with an extended battery option, and the battery is hot-swappable so the device stays in service during a swap.
What security features does the Zebra XSLATE L10 include for enterprise deployments?
The tablet includes a Trusted Platform Module (TPM) and an integrated fingerprint reader to control access to data and applications.
Which industries and use cases is the Zebra XSLATE L10 designed for?
The XSLATE L10 targets field service, logistics, utilities, manufacturing, public safety, and vehicle-mounted applications where a sunlight-readable display, rugged construction, and location-aware connectivity are required.
