Zebra

Zebra LS2208, 1D, SR, multi-IF, kit (USB), anthracite

SKU:

LS2208-7AZU0100ZR

The Zebra LS2208-7AZU0100ZR ships as a USB-only kit — powered and connected through a single USB cable with no separate power supply required — making it the corded, single-interface configuration of the Symbol LS2208 family. Its laser light source delivers a single-line scan pattern at 100 scan/s across a working range that extends to 17 inches, resolving Code 39 elements from 3 mil to 40 mil at a minimum print contrast of 20%. Reading angles reach 60 degrees skew, 65 degrees pitch and 30 degrees roll, and the scanner tolerates ambient light up to 86111 lux. Symbology support spans UPC, Code 128, Code 128 Full ASCII, Code 39 Trioptic, Code 11, Codabar, Interleaved 2 of 5 and Discrete 2 of 5. The Twilight Black housing weighs 5.15 oz and is rated IP30, with a drop specification of multiple drops at 5.0 ft to concrete. RoHS compliance is confirmed, and the unit is suited to retail and education deployments.
Prices could not be updated.
Description
ico-plus ico-minus

The Symbol LS2208 Barcode Scanner is the ultimate solution for efficient and reliable scanning needs. With over eight million units sold, this enterprise-class handheld scanner combines ergonomic design with robust functionality. It supports all standard 1D barcodes and even high-density codes, making it perfect for any inventory or retail environment. Built for durability, it withstands daily wear with a rugged build and long-range scanning capabilities, ensuring a seamless checkout experience and increased productivity for your workforce.


Key Features
  • Durable construction with patented single board design and scratch-resistant tempered glass
  • Class-leading working range captures barcodes from up to 25 inches away
  • Plug-and-play simplicity with universal cable and extensive international keyboard support
  • Ergonomic design reduces user fatigue and enhances productivity
  • Flexible operation with optional Intellistand for hands-free or handheld use

Specifications
  • Physical Characteristics:
    • Dimensions: 6.0 in. H x 2.5 in. W x 3.3 in. D
    • Weight: 5.3 oz./150.0 g
    • Color: Cash Register White, Twilight Black
  • Performance:
    • Scan Speed: 100 scans per second
    • Scanning Technology: 650 nm Laser Diode Class 2
  • User Environment:
    • Operating Temperature: 32° to 122° F
    • Storage Temperature: -40° to 158° F
    • Drop Specification: Multiple drops at 5.0 ft. to concrete
  • Warranty: 5 years on workmanship and materials

Main Features

  • Case color: Black

  • Connectivity: Corded

  • Connection: USB

  • Scanner Capability: 1D

Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Cable
Scanning Capability 1D
Barcode Symbology Supported
  • Full ASCII
  • Discrete 2 of 5
  • Codabar
  • Code 128
  • Code 11
  • UPC
  • Interleaved 2 of 5
  • Code 128 Full ASCII
  • Code 39 Trioptic
Light Source Laser
Scan Rate 100 scan/s
Scan Pattern Single Line
Scanner Range Standard Range
Scanning Distance 17"
Cable Type Included USB
Stand Included No
Reading Angle (Skew) 60°
Reading Angle (Pitch) 65°
Reading Angle (Roll) 30°
Maximum Ambient Light 86111 lux
Drop Specification Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete
Minimum Print Contrast 20%
Minimum Element Resolution (Code 39) 3 mil
Maximum Element Resolution (Code 39) 40 mil
Interfaces/Ports
Host Interface USB
Power Description
Power Source USB
Physical Characteristics
Form Factor Handheld
Rugged Yes
Color Family Black
Product Color Twilight Black
Height 6"
Width 2.5"
Depth 3.3"
Weight (Approximate) 5.15 oz
Miscellaneous
Ingress Protection (IP) Rating IP30
Application/Usage
  • Retail
  • Education
Platform Supported PC
Environmentally Friendly Yes
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Documents
ico-plus ico-minus
Product document ls2208-new.pdf LS2208-7AZU0100ZR  (PDF)
