OVERVIEW
UPC Code 037332247209
Rack Type Floor-Standing
UPS Type On-Line
PDU TypeMetered POWER
Output Power Capacity (kVA) 6
Output Power Capacity (Amps) 26
Output Power Capacity (kW) 5.4
Site Power Required 208/240V, 30A or 230V, 32A, 50/60 Hz
Site Outlet Required Hardwire (208/240V 30A L1-L2-G or 230V 32A L-N-G) COOLING
Cooling Type Passive
Cooling Type Details See Components List for active cooling options OUTPUT
Output AC Waveform (AC Mode) Pure Sine wave
Output AC Waveform (Battery Mode) Pure Sine wave
Usable Outlets (UPS and PDU) (64) C13; (14) C19 INPUT
Nominal Input Voltage(s) Supported 200V AC; 208V AC; 220V AC; 230V AC; 240V AC
Input Phase Single-Phase
Input Plug Type Hard-wire BATTERY
Full Load Runtime (min.) 2 min.
Half Load Runtime (min.) 8.5 min.
Expandable Runtime Yes PHYSICAL
Maximum Device Depth (in.) 37
Rack Height 42U
Usable Rack Space 38U
Total Weight Capacity (lbs.) 3000
Usable Weight Capacity (lbs.) 2584
Unit Dimensions (hwd / in.) 78.5 x 23.63 x 43
Shipping Form Factor Assembled/Tested Unit
Unit Weight (lbs.) 416 ENVIRONMENTAL
Environmental Sensor E2MTHDI COMMUNICATIONS
Network Management Cards WEBCARDLX SPECIAL FEATURES
High Availability UPS Features On-Line (VFI) Operation; Auto Bypass; Battery Backup; Hot swappable batteries; Hot swappable UPS power module
Acoustic Noise Suppression No |
