Label, Die-Cut, Star Blue, TSP743II, mC-Label3

The CSL-RFID CS203X RFID Reader is at the forefront of intelligent technology, designed for seamless integration in various environments. This outdoor-rated reader boasts an impressive reading range of up to 22 meters and can process up to 800 tags per second, making it ideal for applications such as asset management, logistics, and remote monitoring. The built-in event engine allows for intelligent automation, leveraging APIs for simplified connectivity and an open Linux OS for custom application development.

Key Features:

• Built-in Event Engine for Intelligent Automation & IoT integration
• Long read range of up to 22 meters (environment dependent)
• High read rate of 800 tags/second in Maximum Throughput Mode
• Ethernet Connectivity with PoE+ (IEEE.802.3at)
• Seamless Integration with sensors and peripherals via GPIO, USB, Ethernet, and serial connections
• Rich API compatibility including CSL HTTP/XML, LLRP, and MACH1
• IP68 rated for dust and water resistance
• 2-Year Standard Warranty

Specifications:

• Dimensions: 266 mm x 266 mm x 105 mm; Weight: 3.15 kg
• Operating System: Linux
• Processor: Dual Core Arm Cortex® -A9, 1GB DDR3 RAM, 16GB flash
• Read Distance: Up to 22 meters (dependent on tag and environment)
• Protocol: ISO 18000-6C, EPC UHF Class 1 Gen 2
• Power Supply: DC Supply (12V, 5A) or PoE+ (IEEE802.3at)
• Operating Temperature: -20° to 50° C (-4° to 122° F)
• Storage Temperature: -40° to 85° C (-40° to 185° F)
• Humidity: 98% Non-condensing
