Honeywell

Honeywell 7990G Lector de códigos de barras USB, 1D/2D, Imager, Hands-free, IP53

SKU:

7990G-2USBA-1-6

Honeywell SOLARIS-7980G presentation reader designed for high-performance 2D barcode scanning in retail and point-of-sale environments. Compact presentation form factor suited for continuous scanning and streamlined checkout workflows. Model: Honeywell Solaris XP USB ScanMaster (MPN: 7990G-2USBA-1-6). Attributes: - access_control
Description
ico-plus ico-minus
Honeywell’s Solaris 7980GEL Barcode Scanner is engineered to boost checkout efficiency and enhance the customer experience in high-volume retail environments. Its compact, modern design seamlessly integrates into existing setups, making it ideal for convenience, drug, and grocery stores. With advanced Adaptus™ 6.0 area-imaging technology, this scanner reads 1D and 2D barcodes effortlessly, including smartphone displays and digital wallets. Retailers benefit from its omni-directional scanning capability, which ensures quick and accurate scans with minimal fuss. As your data capture needs evolve, the Solaris 7980GEL offers upgrade options from a 1D to a full 2D scanner without the need for any new hardware.
Key Features
  • Versatile Imaging: Scans smartphone coupons, digital wallets, and IDs.
  • Soft LED Illumination: Reduces glare while maintaining performance.
  • Future-proof Design: Upgrade from a linear to a full 2D scanner as needed.
  • Easy Installation: Compatible with most POS systems and includes power-over-USB.
  • User-friendly: Intuitive touch button and LED indicators for easy operation.

Specifications
  • Dimensions: 148 x 152 x 85 mm (5.83 x 5.98 x 3.35 in)
  • Weight: 539g (19 oz.)
  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
  • Storage Temperature: -20°C to 60°C (-4°F to 140°F)
  • Scan Pattern: Area image (1280 x 960 pixel array)
  • Decode Capability: Standard 1D, PDF, 2D, Postal, and OCR symbologies
  • Warranty: 3-year factory warranty
  • Power Supply: 5.2V / 1.0 A
  • Environmental Rating: IP5X

Main Features

  • Rugged: Industrial

  • Range: Standard Range

  • Connection: USB

  • Scanner Capability: Imager, 1D, 2D

Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Cable
Scanning Capability
  • 1D
  • 2D
Barcode Symbology Supported

Decode Capability:

  • Reads standard 1D, PDF, 2D, Postal and OCR symbologies Note: Decode capabilities dependent on kit configuration
Image Sensor Type Imager
Scanner Range Standard Range
Scanning Distance 11.80"
Field of View (Horizontal) 42°
Field of View (Vertical) 34°
Reading Angle (Skew) 75°
Reading Angle (Pitch) 65°
Motion Tolerance 236.22 in/s
Maximum Ambient Light 100000 lux
Minimum Print Contrast 20%
Minimum Element Resolution (Code 39) 5 mil
Maximum Element Resolution (Code 39) 20 mil
Maximum Element Resolution (DataMatrix) 20 mil
Maximum Element Resolution (PDF417) 6.7 mil
Image Sensor Resolution 1280 x 960
Interfaces/Ports
Host Interface USB
Power Description
Input Current 400 mA
Standby Current 270 mA
Environmental Conditions
Operating Temperature 32°F (0°C) to 104°F (40°C)
Storage Temperature -4°F (-20°C) to 140°F (60°C)
Humidity (Non-condensing) 0% to 95%
Physical Characteristics
Form Factor Hands-free
Height 5.8"
Width 6"
Depth 3.3"
Weight (Approximate) 1.16 lb
Miscellaneous
Ingress Protection (IP) Rating IP53
Application/Usage
  • Industrial
  • Retail
  • Convenience Store
Warranty
Limited Warranty 3 Year
Documents
ico-plus ico-minus
Product document 7980g-2021.pdf 7990G-2USBA-1-6 Product document 7980g.pdf MOD-SOLARIS-7980G
