Description
Products and parts from CBC.
Technical Specifications
| Technical Information | |
|---|---|
| Recording Formats | Full HD |
| HD Recording | Yes |
| Display & Graphics | |
|---|---|
| Image Sensor Type | Exmor CMOS |
| Color Supported |
|
| Field of View | Horizontal: Approx. 63.7° (Wide) to 2.3° (Tele) Vertical: Approx. 38.5° (Wide) to 1.3° (Tele) |
| Video | |
|---|---|
| Video Formats |
|
| Maximum Video Resolution | 1920 x 1080 |
| Maximum Frame Rate | 30 fps |
| Video Signal Format |
|
| Lens | |
|---|---|
| Lens Type | Varifocal |
| Minimum Focal Length | 4.30 mm |
| Maximum Focal Length | 129 mm |
| Lens Included | Yes |
| Minimum Aperture | f/4.7 |
| Maximum Aperture | f/1.6 |
| Optical Zoom | 30x |
| Exposure | |
|---|---|
| Shortest Shutter Speed | 1/110000 Second |
| Longest Shutter Speed | 1/1 Second |
| Network & Communication | |
|---|---|
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Storage | |
|---|---|
| Storage Type | Memory Card |
| Interfaces/Ports | |
|---|---|
| Network (RJ-45) | Yes |
| Power Description | |
|---|---|
| Input Voltage | 24 V AC |
| Physical Characteristics | |
|---|---|
| Mount Type | Pendant Mount |
| Durability |
|
| Height | 10.9" |
| Diameter | 9.1" |
| Weight (Approximate) | 10.14 lb |
| Environmental Conditions | |
|---|---|
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Temperature | 122°F (50°C) |
| Maximum Operating Humidity | 85% |
| Miscellaneous | |
|---|---|
| Features |
|
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10 |
| Ingress Protection Rating | IP66 |
| Warranty | |
|---|---|
| Limited Warranty | 36 Month |
