Elo

Sistemas de Punto de Venta Elo E351388

SKU:

E351388

Fitted with TouchPro Projected Capacitive technology supporting 10 simultaneous touch points, the Elo E351388 delivers a 19-inch TFT LCD panel in a 5:4 aspect ratio at 1280 x 1024 SXGA resolution with 250 Nit brightness, a 1,000:1 contrast ratio, and 16.7 million colors. The LED-backlit display carries a 14 ms response time and 178-degree horizontal and vertical viewing angles, while VGA and HDMI video inputs alongside a USB 2.0 touch interface cover connectivity. An integrated USB Hub expands peripheral options, and dual built-in speakers deliver 4 W of audio output. Operating on 100V to 240V and drawing 18 W in use, the panel stands 15.66 inches tall with stand and weighs 13.89 lb configured; without stand it measures 16.9 inches wide by 1.6 inches deep at 9.48 lb. VESA 100 x 100 compatibility supports wall, shelf and pole mounting. A rated MTBF of 5.7 Year and a 3-year limited warranty back the unit for point-of-sale, signage and hospitality deployments.
No se han podido actualizar los precios.
Descripción
ico-plus ico-minus
The Elo 1502L is a 15.6" Full HD LCD touchscreen monitor designed for businesses deploying point-of-sale terminals, self-service kiosks, customer-facing displays, and hospitality applications. Built on Elo's Projected Capacitive (PCAP) multi-touch technology, it supports simultaneous touch input and delivers a 1920 x 1080 resolution across a 16:9 panel with LED backlighting, 700:1 native contrast ratio, and wide 160° horizontal and vertical viewing angles with an anti-glare surface. A single USB Type-C connection carries touch, video, and power, reducing cable clutter and simplifying installation, while HDMI and VGA ports ensure compatibility with existing equipment. The built-in USB hub, integrated speakers, and VESA 100 x 100 mount compatibility — alongside pole, shelf, and wall mount support — give IT teams maximum deployment flexibility across retail, hospitality, and enterprise environments.

Características principales

  • Tocar: Sí

  • Conexión: USB

Especificaciones técnicas
ico-plus ico-minus
Technical Information
Screen Size Class 19"
Viewable Screen Size 19"
Screen Mode SXGA
Panel Technology Thin Film Transistor (TFT)
Response Time 14 ms
Aspect Ratio 5:4
Horizontal Viewing Angle 178°
Vertical Viewing Angle 178°
Mount Type
  • Wall Mountable
  • Shelf Mount
  • Pole Mount
Placement Tabletop
Backlight Technology LED
Features On-screen Display (OSD)
Horizontal Frequency 30 kHz to 82 kHz
Vertical Frequency 50 Hz to 75 Hz
Curved Screen No
Video
Maximum Resolution 1280 x 1024
Color Supported 16.7 Million Colors
Contrast Ratio 1,000:1
Brightness 250 Nit
Maximum Refresh Rate 75 Hz
Audio
Speakers Yes
Number of Speakers 2
Speaker Output Power 4 W
Touchscreen Information
Touchscreen Yes
Touchscreen Type TouchPro Projected Capacitive
Multi-touch Screen Yes
Number of Simultaneous Touchpoints 10
Interfaces/Ports
HDMI Yes
USB Yes
USB Standard USB 2.0
VGA Yes
Built-in Devices
Built-in Devices USB Hub
Power Description
Operating Power Consumption 18 W
Standby Power Consumption 660 mW
Off-Mode Power Consumption 320 mW
Input Voltage Range 100V to 240V
Physical Characteristics
VESA Mount Compatible Yes
VESA Mount Standard 100 x 100
Color Family Black
Product Color Black
Height 14"
Width 16.9"
Depth 1.6"
Height with Stand 15.66"
Width with Stand 16.91"
Depth with Stand 7.61"
Weight (Approximate) 9.48 lb
Weight with Stand (Approximate) 13.89 lb
Miscellaneous
Package Contents
  • 1902L 19" Touchscreen Monitor
  • Japanese Language Regulatory Information Pamphlet
  • Quick Install Guide
  • 3 x Tie Wraps
  • VGA Cable
  • HDMI Cable
  • Touch USB Cable
  • Audio Cable
  • Power Brick
  • Power Cable
  • EEI Label
Mean Time Between Failures (MTBF) 5.7 Year
TAA Compliant No
Warranty
Limited Warranty 3 Year
Documentos
ico-plus ico-minus
Documento del producto 1902l.pdf E351388 Documento del producto touch-solutions-02-series-elo-pos-datasheet-elo-02-series-19inch.pdf TOUCH-SOLUTIONS-02-SERIES Documento del producto touch-solutions-02-series-elo-pos-datasheet-elo-02-series-22inch.pdf TOUCH-SOLUTIONS-02-SERIES Documento del producto touch-solutions-02-series-elo-pos-datasheet-elo-02-series-24inch.pdf TOUCH-SOLUTIONS-02-SERIES Documento del producto touch-solutions-02-series-elo-pos-datasheet-elo-02-series-27inch.pdf TOUCH-SOLUTIONS-02-SERIES Documento del producto touch-solutions-02-series-elo-pos-user-manual.pdf TOUCH-SOLUTIONS-02-SERIES
Preguntas frecuentes
ico-plus ico-minus
¿Qué tecnología táctil utiliza el Elo 02-Series 1302L y cuántos toques simultáneos soporta?
El Elo 1302L utiliza la tecnología TouchPro PCAP (capacitativa proyectada) de Elo con vidrio de borde a borde y soporta hasta 10 toques simultáneos.
¿Qué opciones de conectividad de video y datos están disponibles en el Elo 02-Series 1302L?
El 1302L ofrece USB Tipo-C, que transporta energía, táctil y video a través de un solo cable, así como entradas HDMI y VGA para su uso con sistemas que no tienen USB Tipo-C.
¿Cuál es la resolución nativa de la pantalla y el brillo del Elo 1302L?
El 1302L tiene un panel LCD TFT de matriz activa de 13.3 pulgadas con una resolución nativa de 1920 x 1080 en una relación de aspecto de 16:9, con un brillo del panel clasificado en 300 nits y 270 nits cuando se mide a través de la capa táctil PCAP.
¿Qué tipos de entrada reconoce la pantalla táctil Elo 1302L?
El 1302L es compatible con entradas de dedo, guante y lápiz óptico.
¿Qué opciones de montaje son compatibles con el Elo 02-Series 1302L?
El 1302L admite configuraciones de montaje en soporte, pared y poste, brindando a los integradores flexibilidad para mostradores de POS, recintos de quioscos e instalaciones orientadas al cliente.
¿Qué garantía tiene el Elo 02-Series 1302L?
El Elo 1302L cuenta con una garantía estándar de tres años.
