CBX500 Ethernet All-in-one, BM

Datalogic's CBX Series Fixed Barcode Scanner offers an efficient, cost-effective solution designed to streamline installations, configurations, and maintenance of Datalogic Automation's 1D/2D code readers. With its robust industrial design, the CBX Series ensures minimal downtime, facilitating quick replacements and enhanced productivity. The variety of optional modules allows seamless connectivity with common fieldbus systems, enabling easy cabling operations and simplified network management in manufacturing and warehousing environments.
Key features:

• Cost-effective solution with reduced ownership costs and minimal installation time.
• Easily installed with accessible through-holes and optional adapters for quick mounting.
• Simplified wiring through standardized pinouts and spring clamps for easy operation.
• Rapid maintenance access for service interface and code reader diagnostics.
• IP65 (NEMA 4) rated for robust industrial applications with temperature ranges from -35°C to +50°C.
• Multilanguage display for convenient monitoring and troubleshooting.

Specifications:

• Dimensions (CBX100): 128 x 137 x 62 mm
• Weight (CBX100): 380 g
• Power Supply: 10 to 30 VDC
• Power Consumption: 2.5 W max
• Operating Temperature: 0 to 50 °C (32 to 122 °F)
• Protection Class: IP65
• Diagnostic LED Indicators: Power On, Polarity Error, Trigger, IN2, OUT1, OUT2
• Compatible Devices: CBX100 compatible with DS2100N, DS2400N, and more.
