Zebra TC26-HC Mobile Computer Healthcare, 5.0 in, 3GB/32GB, LTE WAN, GPS, IP67
TC26AK-1JB224-NAP
Select model
The Zebra Mediclean Pro Touch is a healthcare-grade handheld mobile computer designed to streamline clinical and ancillary workflows where hygiene, connectivity and reliable data capture are essential. Built on the proven TC26 platform, it provides point-of-care access to patient records, barcode scanning and secure communication for hospitals, clinics, long‑term care and field health services. The device combines a glove‑friendly 5‑inch HD touchscreen with disinfectant‑ready chemical-resistant housing, Gorilla Glass protection and IP67 sealing to tolerate routine cleaning and daily handling. With integrated Wi‑Fi, LTE, Bluetooth, NFC and GPS, a programmable rear alert button, removable PowerPrecision battery and SE4100 imaging, it helps teams stay connected, efficient and infection‑control compliant during long shifts.
Key Features
- Healthcare-ready construction: Disinfectant‑ready chemical-resistant plastics and IP67 sealing support frequent cleaning and infection‑control protocols.
- Reliable data capture: SE4100 1D/2D imager and optional camera support fast barcode scanning, patient identification and documentation workflows.
- Always‑connected mobility: Wi‑Fi, LTE/4G, Bluetooth and NFC (plus integrated GPS on select models) enable real‑time access to clinical systems across facilities and in the field.
- Glove‑friendly touchscreen: A 5‑inch advanced HD capacitive multi‑touch display remains responsive with gloves and includes Gorilla Glass protection for durability.
- Shift‑ready power: Removable/swappable PowerPrecision battery designs (standard ~3100 mAh) and up to approximately 10 hours typical runtime support extended use.
- Rapid response tools: Programmable rear alert button, push‑to‑talk and vibration features improve staff communication and emergency response.
Specifications
- Brand: Zebra
- Category: Handheld Computers
- Platform / Model Family: TC26 Healthcare series
- Processor: Qualcomm Snapdragon 660 / SD660
- RAM: 3 GB
- Storage Capacity: 32 GB flash
- Display Size: 5.0 in
- Display Type: Advanced HD capacitive multi‑touch
- Display Resolution: 1280 x 720 px (select variants)
- Display Protection: Corning Gorilla Glass
- Scanner / Imager: SE4100 1D/2D imager
- Connectivity: Wi‑Fi, 4G (LTE), Bluetooth
- NFC Support: Integrated NFC (select variants)
- GPS: Integrated GPS (select variants)
- Operating System: Android 10 or Android 11 (varies by variant)
- Battery Type: Removable PowerPrecision lithium‑ion
- Battery Capacity: ~3100 mAh (select variants)
- Typical Battery Runtime: Up to ~10 hours (typical)
- Programmable Alert Button: Rear programmable healthcare alert button
- Housing Material: Chemical‑resistant healthcare plastics (disinfectant‑ready)
- Ingress Protection: IP67
- Ruggedness: Drop resistance / MIL‑STD durability features on select variants
- Rear Camera / Front Camera: 13 MP rear and 5 MP front (available on multiple variants)
Main Features
-
Target Industry: Healthcare
-
Operation System: Android
-
Rugged: Commercial
-
RAM/FLASH: 3GB / 32 GB
-
Battery Capacity: Standard
-
GPS: Yes
-
Range: Short Range
-
Connection: Bluetooth, USB
-
Pin: 0
-
Camera: None
-
Battery Features: Rechargeable
| Technical Information | |
|---|---|
| Connectivity Technology | Wireless |
| Scanning Capability |
|
| Scan Engine Model | SE4100 |
| Image Sensor Type | Imager |
| Scanner Range | Standard Range |
| Google Mobile Services (GMS) | Yes |
| Sensor Type |
|
| Multi-SIM Supported | Yes |
| Number of SIM Card Supported | 1.0 |
| SIM Size Supported | Nano/eSIM |
| Features |
|
| Drop Specification |
4 ft./1.2 m drops to vinyl tile over concrete per MIL-STD 810G across operating temperature |
| Illumination Type | LED |
| Illumination Color | White |
| Processor & Chipset | |
|---|---|
| Processor Manufacturer | Qualcomm |
| Processor Type | Snapdragon |
| Processor Model | 660 |
| Processor Core | Octa-core (8 Core) |
| Processor Speed | 2.20 GHz |
| Memory | |
|---|---|
| Standard Memory | 3 GB |
| Flash Memory | 32 GB |
| Memory Card Supported | microSD |
| Display & Graphics | |
|---|---|
| Screen Size | 5" |
| Screen Mode | HD |
| Screen Resolution | 1280 x 720 |
| Display Screen Type | LED |
| Touchscreen Information | |
|---|---|
| Touchscreen | Yes |
| Multi-touch Screen | Yes |
| Keyboard/Keypad | |
|---|---|
| Buttons & Keys |
Scan on each side; volume up/down; power; push-to-talk (PTT) keys; HC Alert key |
| Network & Communication | |
|---|---|
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w |
| Bluetooth | Yes |
| Bluetooth Standard | Bluetooth 5.0 BLE |
| Near Field Communication (NFC) | Yes |
| Cellular Data Connectivity Technology |
|
| GPS | Yes |
| Global Navigation Satellite System (GNSS) Supported | BeiDou/Galileo/GLONASS |
| Interfaces/Ports | |
|---|---|
| USB | Yes |
| USB Type-C | Yes |
| Camera | |
|---|---|
| Front Camera | Yes |
| Front Camera Resolution | 5 Megapixel |
| Rear Camera | Yes |
| Rear Camera Resolution | 13 Megapixel |
| Software | |
|---|---|
| Operating System | Android 10 |
| Upgradable Operating System | Android 14 |
| Power Description | |
|---|---|
| Power Source | Battery |
| Battery Information | |
|---|---|
| Battery Capacity | 3100 mAh |
| Battery Chemistry | Lithium Ion (Li-Ion) |
| Battery Included | Yes |
| Removable Battery | Yes |
| Environmental Conditions | |
|---|---|
| Operating Temperature | 14°F (-10°C) to 122°F (50°C) |
| Storage Temperature | -22°F (-30°C) to 158°F (70°C) |
| Humidity (Non-condensing) | 5% to 95% |
| Physical Characteristics | |
|---|---|
| Form Factor | Phone-size |
| Rugged | Yes |
| Height | 6.1" |
| Width | 3.1" |
| Depth | 0.5" |
| Weight (Approximate) | 8.43 oz |
| Miscellaneous | |
|---|---|
| Application/Usage | Healthcare |
| Ingress Protection (IP) Rating | IP67 |
| Environmentally Friendly | Yes |
| Environmental Certification |
|
| Warranty | |
|---|---|
| Limited Warranty | 1 Year |
