Elo M60 Mobile POS, Android 10, 3GB RAM, 32GB, 6", IP65, GPS
E863128
Select model
The Elo M60 Pay Mobile POS Computer is engineered for the modern business landscape, combining versatility with power. Featuring a vibrant 6-inch HD touch display, this all-in-one platform runs on Android 10, powered by a Qualcomm 660 octa-core processor. With integrated payment options and robust device management through EloViewⓇ, the M60 Pay allows staff to process transactions seamlessly and efficiently, whether in-store or on the go. Built to withstand the rigors of commercial use, the M60 Pay's rugged design includes Corning Gorilla Glass for added protection, ensuring it meets the demands of any fast-paced environment.
Key Features
- 6" HD Touch Display for clear visibility
- Integrated Payment Options: NFC, EMV, and MSR
- Rugged Design: Corning Gorilla Glass for durability
- Android 10 Operating System with planned upgrade to Android 12
- Seamless Device Management via EloView or 3rd-party MDM
- Secure and Certified: PCI-PTS 6.0 certified
Specifications
- Display: 6" Optically Bonded HD LCD
- Processor: Qualcomm Snapdragon 660, 2.2GHz Octa-Core
- Memory: 3GB RAM
- Storage: 32GB (Expandable via MicroSD)
- Wireless: 802.11a/b/g/n/ac, Bluetooth 5.0
- Battery: 4000mAh Li-Polymer with Qualcomm Quick Charge 4
- Dimensions: 7.32" x 3.40" x 0.77"
- Weight: 0.79 lbs
- Operating Temperature: 32°F to 122°F (0°C to 50°C)
- Sealing Rating: IP54 for dust and moisture resistance
- Warranty: 1-year standard; options for extended coverage
Main Features
-
Operation System: Android
-
Rugged: Commercial
-
GPS: Yes
-
Range: Short Range
-
Connection: USB, NFC
-
Camera: 8MP
-
Included Battery: Yes
-
Battery Features: Rechargeable
| Technical Information | |
|---|---|
| Connectivity Technology | Wireless |
| Scanning Capability |
|
| Google Mobile Services (GMS) | Yes |
| Sensor Type |
|
| Brightness | 430 Nit |
| Features |
|
| Drop Specification |
(1 m) |
| Processor & Chipset | |
|---|---|
| Processor Model | 660 |
| Processor Core | Octa-core (8 Core) |
| Processor Speed | 2.20 GHz |
| Memory | |
|---|---|
| Standard Memory | 3 GB |
| Flash Memory | 32 GB |
| Memory Card Supported |
|
| Display & Graphics | |
|---|---|
| Screen Size | 6" |
| Screen Mode | HD |
| Screen Resolution | 1440 x 720 |
| Display Screen Type | LCD |
| Touchscreen Information | |
|---|---|
| Touchscreen | Yes |
| Multi-touch Screen | Yes |
| Network & Communication | |
|---|---|
| Wireless LAN | Yes |
| Wireless LAN Standard | IEEE 802.11a/b/g/n/ac |
| Bluetooth | Yes |
| Bluetooth Standard | Bluetooth 5.0 |
| Near Field Communication (NFC) | Yes |
| Cellular Data Connectivity Technology | 4G LTE |
| GPS | Yes |
| Interfaces/Ports | |
|---|---|
| USB | Yes |
| USB Type-C | Yes |
| Camera | |
|---|---|
| Rear Camera | Yes |
| Rear Camera Resolution | 8 Megapixel |
| Software | |
|---|---|
| Operating System | Android 10 |
| Upgradable Operating System | Android 12 |
| Battery Information | |
|---|---|
| Battery Capacity | 4000 mAh |
| Battery Chemistry | Lithium Polymer (Li-Polymer) |
| Battery Included | Yes |
| Maximum Battery Run Time | 12 Hour |
| Battery Voltage | 3.80 V |
| Environmental Conditions | |
|---|---|
| Operating Temperature | 32°F (0°C) to 122°F (50°C) |
| Storage Temperature | -22°F (-30°C) to 140°F (60°C) |
| Humidity (Non-condensing) | 5% to 95% |
| Physical Characteristics | |
|---|---|
| Product Color | Black |
| Rugged | Yes |
| Weight (Approximate) | 12.64 oz |
| Miscellaneous | |
|---|---|
| Package Contents |
|
| Application/Usage |
|
| Ingress Protection (IP) Rating | IP54 |
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS) |
| Warranty | |
|---|---|
| Limited Warranty | 1 Year |
