ET1504L-2UWA-1-BL-G
E969493
Select model
The Elo 1504L 15.6-inch touchscreen monitor combines sleek design with commercial-grade reliability, perfect for various business applications. Its optically-bonded, edge-to-edge glass display supports up to 10 simultaneous touches, ensuring a highly responsive experience. Designed to withstand demanding environments, the 1504L features an IP54-sealed construction, protecting it against dust and spills. With multiple connectivity options, including USB Type-C, HDMI, and DisplayPort, this monitor is versatile for point-of-sale systems, kiosks, and more, making it an ideal choice for businesses looking to enhance their customer interactions.
Key Features
- Touch Pro® PCAP technology: Supports up to 10 simultaneous touches for precise interaction.
- Durable design: Optical bonding and IP54 protection for enhanced durability.
- Flexible connectivity: USB Type-C, HDMI, DisplayPort, and more to meet diverse needs.
- Multiple mounting options: Comes with options for stands, wall mounts, and pole mounts.
- Integrated speakers: Dual 2W internal speakers for clear audio output.
Specifications
- Model: 1504L
- Color: Black
- Diagonal Size: 15.6 inches / 419.1 mm
- Active Display Area: 13.55" x 7.62" / 344.16 mm x 193.5 mm
- LCD Technology: Active matrix TFT LCD
- Native Resolution: 1920 x 1080
- Aspect Ratio: 16:9
- Response Time: 25 ms
- Brightness: 450 nits
- Contrast Ratio: 1000:1
- Input Ports: USB Type-C, DisplayPort, HDMI, USB Type-A, and more
- Weight: 3.74 lbs (without stand)
- Operating Temperature: 0 °C to 40 °C
- Humidity (non-condensing): 20%-80%
- Warranty: 3 years standard
Main Features
-
Touch: Yes
-
Connection: USB
| Technical Information | |
|---|---|
| Screen Size Class | 16" |
| Viewable Screen Size | 15.6" |
| Screen Mode | Full HD |
| Placement | Tabletop |
| Features |
|
| Video | |
|---|---|
| Maximum Resolution | 1920 x 1080 |
| Touchscreen Information | |
|---|---|
| Touchscreen Type | Projected Capacitive |
| Multi-touch Screen | Yes |
| Number of Simultaneous Touchpoints | 10 |
| Interfaces/Ports | |
|---|---|
| HDMI | Yes |
| USB | Yes |
| DisplayPort | Yes |
| USB Type-C | Yes |
| Physical Characteristics | |
|---|---|
| Color Family | Black |
| Product Color | Black |
1504L_15_6.pdf E969493
1504L_15_6.pdf MOD-1504LS
