Unitech

Lecteurs Unitech AS10-U

UGS :

AS10-U

The Unitech MS335 is a high performance linear imager barcode scanner that delivers reliability and durability at an affordable price. Designed to meet the needs of business applications such as retail, office automation, healthcare, postal distribution, and light industrial; the MS335 provides the features needed to optimize productivity
Description
ico-plus ico-minus

The Unitech AS10 Barcode Scanner is an economical and durable solution designed for various environments, including retail, medical, and light industrial applications. Its built-in powerful decoder simplifies data processing by reading all major barcode symbologies, enhancing accuracy while reducing labor costs. With comprehensive configuration options, you can tailor settings across multiple scanners, ensuring efficiency and consistency in your operations.


Key Features:
  • Complete data formatting and editing capabilities
  • Reads most commonly used barcode symbologies
  • Easy to use and configure
  • Ergonomic design
  • Economical and durable

Specifications:
  • Physical Characteristics:
    • Length: 179.7 mm
    • Width: 81 mm
    • Height: 63.5 mm
    • Weight: Approximately 4.23 oz. (120 g)
    • Housing Material: ABS
  • Electrical:
    • Voltage: DC +5V ±5%
    • Power Consumption: 80mA
    • EMC: FCC Part 15 Class B, EN55022, EN55024
  • Environmental:
    • Operating Temperature: 0°C to 50°C (32°F to 122°F)
    • Storage Temperature: -20°C to 70°C (-4°F to 158°F)
    • Relative Humidity: 20% to 95% (Non-condensing)
    • Drop: 47.24 inches (120cm) on concrete
    • Ambient Light: 5000 Lux Max.
  • Scan Performance:
    • Depth of Field: 60mm@20mil/0.5mm, PCS90%
    • Scan Rate: 100 scans/sec
    • Resolution: 5mil/0.127mm@PCS90%
  • Operational:
    • Light Source: Visible red light 632nm LED
    • Interfaces: RS232, KBW, USB
    • Cable: Straight 5 ft.
    • Connector: RJ45 phone jack connector
    • Reading Indicator: Beeper
  • Readable Symbologies:
    • GS1 DataBar
    • UPC/EAN/JAN
    • Code 39
    • EAN128
    • Full ASCII
    • Code 128
    • Interleave 25
    • Matrix 25
    • CODABAR/NW7
    • Code 11
    • MSI/PLESSEY
    • Code 93
    • China Postage
    • Code 32/Italian Pharmacy
  • Warranty: 1 year

Caractéristiques principales

  • connectivité: Corded

  • Connexion: USB

  • Capacité de numérisation: 1D

Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Cable
Image Sensor Type CCD
Scan Rate 100 scan/s
Maximum Scan Resolution 5 mil
Depth of Field
  • 60mm@20mil - PCS 90%
Scan Pattern Linear
Interfaces/Ports
Host Interface USB
Physical Characteristics
Form Factor Handheld
Product Color Black
Height 7.1"
Width 3.2"
Depth 2.5"
Weight (Approximate) 4.23 oz
Miscellaneous
Additional Information

USB Cable separate
Warranty
Limited Warranty 1 Year
Documents
ico-plus ico-minus
Document produit as10-unitech.pdf AS10-U Document produit unitech-ms335-ccd-scnr.pdf AS10-U Document produit as10-unitech.pdf MOD-AS10
