Socket SoMo 655 Scan Plug-In 5P, C2 Laser, Black - Docking
ico-puzzle-piece-02 Ce produit est compatible avec...
Description
ico-plus ico-minus
CF Scan Card 5P from Socket is an advanced-level scanner that adds affordable barcode scanning to your Pocket PC device. Based on revolutionary laser technology from Symbol Technologies, the CF Scan Card 5P scans all popular linear barcode symbologies. It is equipped with a powerful Class 2 laser scanning engine for high-volume, high-speed scanning. Its state-of-the-art laser technology enables the reading of damaged, poor quality and hard-to-read barcodes, even on curved and reflective surfaces and in dim environments. CF Scan Card 5P consumes minimal power during scanning to maximize battery life. SocketScan keyboard emulation software sends decoded data to any Windows application as virtual keystrokes. The integrated Type II CF card and scanner plugs into the Type II CompactFlash slot of Windows-powered Pocket PCs. With the optional CF-to-PC card adapter, CF Scan Card 5P can also be used in pen tablets or laptops. CF Scan Card 5P requires no extra batteries or special power adapter.
Technical Specifications
ico-plus ico-minus
Technical Information
Connectivity Technology Plug-in Card
Scanning Capability 1D
Barcode Symbology Supported
  • Chinese 2 of 5
  • Codabar
  • Code 11
  • Code 128
  • Code 39
  • Code 93
  • D 2 of 5
  • GS1-128 (UCC-128/EAN-128)
  • GS1 DataBar (RSS)
  • I 2 of 5
  • MSI
  • UPC/EAN
Light Source Laser
Scan Rate 100 scan/s
Depth of Field
  • 3.5" - 5"@5mil
  • 3" - 7.5"@7.5mil
  • 2.25" - 9.7"@7.5mil
  • 2.5" - 12"@100% UPC
  • 15"@20mil
  • 22"@40mil
  • 24"@55mil
Scan Pattern Bi-directional
Scanning Distance 45"
Interfaces/Ports
Host Interface CFIO
Power Description
Input Voltage 3.3 V DC
Physical Characteristics
Height 0.8"
Width 1.6"
Depth 2"
Weight (Approximate) 1.20 oz
Miscellaneous
Package Contents
  • CompactFlash Scan Card
  • SocketScan Software Media
  • Retaining Bracket
Additional Information

USB Cable separate

Compatibility
  • Windows Mobile for Pocket PC 2000/2002/2003
  • HPC 2000
  • Windows XP
Platform Supported
  • PC
  • Smartphone
Certifications & Standards EMI/RFI:
  • FCC Part 15,
  • Class B,
  • CISPR 22,
  • ICES-003 Class B,
  • CE EN 55024:2003,
  • Japan VCCI Class B,
  • AS 3548,
  • C-Tick s.82
Laser/LED Safety:
  • IEC60825-1 Class 1 Laser
  • 21 CFR 1040.10
  • 21 CFR 1040.11
Environmentally Friendly No
Environmental Certification
  • RoHS
  • REACH
Warranty
Limited Warranty 1 Year
