Digi

Accessories Digi 301-1001-11

UGS :

301-1001-11

Digi Edgeport/1 USB-to-Serial Adapter - 1 Pack - 1 x Type B Female USB - 1 x DB-9 Male Serial
ico-puzzle-piece-02 Ce produit est compatible avec...
Description
ico-plus ico-minus

The Digi Edgeport USB-to-Serial Converter is your reliable solution for seamless peripheral connectivity. With the ability to expand your PC, thin client, or server by adding up to 16 serial ports, this converter ensures rapid deployment without the need for system reconfiguration. Its versatile design supports a variety of operating systems including Windows and Linux, making it ideal for multiple applications ranging from point-of-sale systems to industrial automation. With robust construction and hot-swappable capabilities, the Digi Edgeport ensures optimal performance even in demanding environments.


Key Features:
  • Adds **1 to 16 serial ports** to your device in minutes
  • Compatible with **multiple operating systems** including Windows NT, 2000, and Linux
  • Designed for **industrial, medical, and retail applications**
  • **Hot-swappable** for easy connection and disconnection
  • Lower **total cost of ownership** with external installation

Specifications:
  • **Interface:** USB 1.0 and 1.1 compatible
  • **Baud rate:** Up to 230 Kbps per serial port
  • **Connectors:** DB-9, DB-25, RJ-45 available
  • **Power Requirements:** USB-powered for models without USB ports
  • **Operating Temperature:** 32°F to 131°F (0°C to 55°C)
  • **Dimensions:** Various models, check specifications for details
  • **Certifications:** USB-IF certified, FCC Part 15, Class B, CE compliant
Technical Specifications
ico-plus ico-minus
Technical Information
Adapter Type Serial/USB
Connector Type on First End USB 2.0 Type B - Female
Connector on First End Details 1 x 4-pin Type B USB 2.0 USB Female
Connector Type on Second End DB-9 RS-232 Serial - Male
Connector on Second End Details 1 x 9-pin DB-9 RS-232 Serial Male
Physical Characteristics
Height 0.8"
Width 1.8"
Depth 3.2"
Weight (Approximate) 1.60 oz
Miscellaneous
Package Contents
  • Edgeport/1
  • 1-meter USB cable
Additional Information
  • Plug and Play
  • Hot-swappable
  • USB 1.0, 1.1 and 2.0 compliant
  • No external power supply needed
  • UART: 128-byte buffer per direction
Compatibility
  • PDA -
  • Printer -
  • Barcode -
  • Scanner - & other serial Peripheral Device
Certifications & Standards
  • CE
  • UL 1950
  • CSA No. 950
  • FCC Part 15 Class B
  • EN55022 Class B, 55024, 60950
Warranty
Limited Warranty 5 Year
