Altronix

Accessories Altronix RBST

UGS :

RBST

Relay Module (6VDC, 12VDC or 24VDC Operation)
ico-puzzle-piece-02 Ce produit est compatible avec...
Les prix n’ont pas pu être mis à jour.
Description
ico-plus ico-minus
The Altronix ALTV2416 Power Supply provides 24VAC or 28VAC distributed via sixteen (16) fuse or PTC protected outputs for powering CCTV Cameras, heaters and other video accessories. It has a supply current of 24VAC @ 8 amp (200VA) or 28VAC @ 7 amp (200VA). Main fuse is rated @ 10 amp/250V. It has a power ON/OFF switch. ALTV2416 Power Supply's ease of installation saves time and eliminates costly labor.
Spécifications techniques
ico-plus ico-minus
Physical Characteristics
Height 1"
Width 2"
Depth 2.8"
Weight (Approximate) 7.68 oz
Miscellaneous
Additional Information
    Input Voltage:
    • 6VDC, 12VDC or 24VDC operation
    • Current draw: 30mA
    Contact Rating:
    • 1 amp/120VAC or 2 amp/28VDC DPDT contacts
    Electrical:
    • Operating temperature: -25° C to 55° C ambient
    System AC input VA requirement:
    • 6VDC: 1.8VA
    • 12VDC: 3.6VA
    • 24VDC: 7.2VA
    Environmentally Friendly Yes
    Environmental Compliance Restriction of Hazardous Substances (RoHS)
    Warranty
    Limited Warranty Lifetime
